STUDS AND SOCKETS FOR RIVETING

• Creates earth grounding points (common ground points) on
Benchware & Field Service
bench and floor mats to which to connect ground cords
• Made in Britain 230630
Part No. Description
230630 10mm Stud and Post, Pack of 100
230675 10mm Socket and Post, Pack of 100
230675

PUNCH AND ANVIL Ideal for use with
• Used to fix studs or sockets to mats our bench matting
• Non-slip grip sleeve
• Supplied with 10 studs and posts
• Made in Britain
Part No. Description 230660
230660 Punch and Anvil for 10mm Stud and Post

Download Technical Drawing 230660

CRIMP-ON STUDS AND SOCKETS FOR MATS

• Prongs are designed to pierce bench mat
• Prongs fold over on underside of mat to hold 10mm stud or socket in place
• Made of stainless steel
• Recommended for 3-layer matting with conductive scrim
Part No. Description
230670 Crimp-on 10mm Stud
230680 Crimp-on 10mm Socket 230670
230680
SCREW-ON STUDS
• Create grounding points on bench tops or chassis
• Machined stud with M4 internal thread is made of stainless steel
• Wood screw length is 16mm, stud is made of plated brass
• Not recommended for 3-layer matting with conductive scrim
• Made in Britain
230650
Part No. Description 230645
230645 10mm Stud, M4 Thread with Screws and Washer
230650 10mm Stud, with Wood Screw

SCREW-ON STUD WITH FACE PLATE

• Create designated ESD grounding point (common
ground points) on panels, racks, cabinets, etc.
• Available in two versions: 10mm connector to be electrically bonded
to mounting or to earth by user, or supplied with a 1Megohm
(1x10E6 ohms) resistor built into the 1.5m straight cord
• Straight cord can be shortened; spare ring terminal is supplied
• Maximum mounting panel thickness: 3.5mm; drill 231110
6mm hole in panel to mount
• Supplied as a kit with assembly instructions
Part No. Description
231105 EBP, Kit, 10mm Stud (No Wire)
231110 EBP, Kit, 4mm Banana Socket, with Lead
and 1 Megohm Resistor

Download Technical Drawing 231105
