P. 388
INSULATED TOOLS
KNIPEX X-Cut ® 2QYGTHWN NKIJV CPF WPKXGTUCN
Compact Diagonal Cutters Cuts precisely finest strands as well as
DIN ISO 5749 IEC 60900 DIN EN 60900 73 multi-core cables and piano wires
> box joint design: highest stability with low weight
> doubly supported joint axis for heaviest duty
> high cutting capacity with very little effort thanks to the
optimum co ordination of cutting edge angle and leverage ratio
> large opening width for thicker cables
> cuts precisely, even through fine copper wires
> compact, low weight construction
> universally usable, in the assembly, maintenance and production
> Chrome vanadium heavy duty steel, forged, multi stage oil hardened
Product video
X-Cut ®
40 % less effort required
73 06 160
compared to standard diagonal cutters of the same length.
With double mounted hinged joint.
Cutting capacities
EAN
Article No 003773 mm Pliers Handles Ø mm Ø mm Ø mm Ø mm Ø mm g
chrome insulated with multi component grips,
73 06 160 0751 1 160 8 3 8 2 7 2 2 12 0 175
plated VDE tested
High Leverage Diagonal Cutters
DIN ISO 5749 IEC 60900 DIN EN 60900 74
> with integrated forged axle for heaviest duty
> suitable for all types of wire including piano wire
> high cutting performance with minimum effort due
to optimum co ordination 74 06 200
> of the cutting edge angle and transmission ratio
> precision cutting edges additionally induction hardened,
cutting edge hardness approx 6 HRC
> Chrome vanadium heavy duty steel, forged, multi stage oil hardened
Length 250 mm
the 250 mm long diagonal cutter is suitable for copper conductors
up to 16 mm² and aluminium conductors up to 35 mm²
74 07 200
20 % less effort required
EQORCTGF VQ EQPXGPVKQPCN FKCIQPCN EWVVGTU QH VJG UCOG
length. With integrated forged joint axle.
Cutting capacities
EAN
Article No 003773 mm Pliers Handles Ø mm Ø mm Ø mm g
74 06 160 0 0705 160 3 2 5 2 0 215
74 06 180 022985 180 chrome insulated with multi component grips, 3 8 2 7 2 2 280
74 06 200 033820 200 plated VDE tested 2 3 0 2 5 308
74 06 250 0 1955 250 6 3 5 3 0 53
74 07 200 018 1 200 chrome 2 3 0 2 5 328
with dipped insulation, VDE tested
74 07 250 018 21 250 plated 6 3 5 3 0 510
205
