CIRCLIP PLIERS


 Circlip Tool
 for large internal and external circlips up to 1000 mm  46

   > universally usable for large circlips with diameters of  00   1000 mm
 reliable opening and closing of the circlips and holding by self locking
 precision spindle drive
   > for fitting and removing circlips
   > circlips are reliably catched thanks to short, direct attachment
   > replaceable tips having working ends with diameters of 6 and 9 mm,
 for perfect adaption to the handling bores in the circlips
   > optional operation by hand, with Allen key, ratchet wrench or
 cordless screwdriver
   > areas of application are heavy engines where very high forces
 and torques are transmitted with large shafts and bearings,
 e g  wind turbines, tidal power stations, generator construction,
 hydropower stations, large machine construction (rolling mills,
 presses), shipbuilding, aerospace
   > tool in a plastic case with foam insert
   > tip material: chrome vanadium electric steel  46 10 100

















 Manually operable  Machine operable
























 Replaceable inserts for internal and external circlips

















 EAN  Size of bore       Size of shaft
 Article No    003773   Ø mm  Ø mm                 g
 46 10 100  075 17      00   1000   00   1000     2200
