Circuit board holder
Circuit board holder
WBHS circuit board holder with a pivoting stand for the
hot air pencil. Circuit boards up to 310 x 320 mm can be
accommodated. The circuit board holder ensures that the hot-
air pencil is vertical to the printed circuit board under repair
and the pivoting stand allows the hot-air pencil to be raised
and lowered precisely onto the component being reworked.
WBHS PCB board holder with stand
PCB board holder with stand for WHA
3000P, WHA 3000V and WTHA 1
Order No. T005 33 165 99N
Max. size 310 x 320 mm
Board positioning in X and Y directions
For single and double-sided boards
Stand to mount HAP 3000 or WTHA 1 hot-air pencil
WHP 3000 preheating plate could be
fitted under the board holder
WBH PCB board holder without stand
PCB board holder without stand
Order No. T005 33 164 99N
For retaining and securing the circuit boards under repair.
Same as WBHS but without stand
