Concept 1

accessories 3

See additional accessories, lighting units, paper 13 2
roll holders and cutters on pages 9-11.

10
12
6
4 11
Cable cover, TTS-shelf

9
5 7 5
14
Shelf for packing material SPM

8
Fastening parts for SPM-shelf

Name Description Size W x D x H mm Suitability / module Code
1. Light and balancer rail Luminares are fitted to light/balancer rails which are height and 1500 2 x M750 918 49 006P
depth adjustable. Max load 15 kg. 1800 2 x M900 918 49 008P
2. Tiltable top shelf TTS Tiltable steel shelf with front lip. Max tilt 12,5°. Front lip height 717 x 400 x 32 M750 TTSM7504-49
30 mm. Can also be installed at the back of the shelf. Can be 870 x 400 x 32 M900 TTSM9004-49
equipped with PDH400 dividers and CCM-cable cover. Fixing 1467 x 400 x 32 M1500 TTSM15004-49
points for TNL-lighting units. Max load 80 kg.
1773 x 400 x 32 M1800 TTSM18004-49
3. Divider hoops set (4 pcs), Adjustable divider hoop set for the TTS-shelves of depth 400 8 x 400 x 400 TTS-shelves PDH400-49
TTS-shelf mm. Can be tightened under the shelf with the screws. depth 400
4. Cable cover, TTS-shelf With cable cover, you can conveniently hide the cables under 612 x 125 x 19 M750 CCM750-49
the shelf. The cover is 125 mm deep and it covers whole shelf. 815 x 125 x 19 M900 CCM900-49
Suitable for TTS-shelf. 1362 x 125 x 19 M1500 CCM1500-49
1666 x 125 x 19 M1800 CCM1800-49
5. Shelf for packing material SPM 600 mm deep shelf for many purposes. The shelf does not 467 x 600 x 32 M500 SPM500-49
include fastening parts. Fastening parts are ordered separately 717 x 600 x 32 M750 SPM750-49
from the following options. The shelf can also be equipped with 870 x 600 x 32 M900 SPM900-49
PDH600 divider hoops. Max load 60 kg.
1167 x 600 x 32 M1200 SPM1200-49
1317 x 600 x 32 M1350 SPM1350-49
1467 x 600 x 32 M1500 SPM1500-49
1773 x 600 x 32 M1800 SPM1800-49
6. Brackets for Concept Fastening set for the fixed lower shelf. With fastening set you can SPM-shelves SPMH-49
accessory bar, SPM-shelf fit SPM-shelf to the accessory bar of Concept. Concept
7. Adjustable fastening set under Mounting parts for height adjustable lower shelf. SPM-shelf can 90 x 350 x 355 SPM-shelves SPMAF-49
worktop, SPM-shelf be fitted under worktop with mounting parts. Free space 285- Concept, TPB
465 mm on lower shelf.
8. Brackets for upright tube, Mounting parts for top shelf to the upright tube. With the SPM-shelves SPMBS-49
SPM-shelf mounting kit, you attach the SPM shelf to the upright tube. Concept
9. Divider hoops set (4 pcs), Divider hoop set for the SPM-shelves. The fixed divider is 8 x 400 x 280 SPM-shelves PDH600-49
SPM-shelf tightened with the screw at the front edge of the shelf.
10. Adjustable auxiliary top Ergonomic tilt adjustable tray with double arm (0-25°). Lipped 560 x 340 927 41 001P
edge of 15 mm. Max load 15 kg.
11. Equipment tray With double arm and handle. For small tools and packing 500 x 250 x 125 928 49 002P
accessories such as BLD20 (page 9). Max load 15 kg.
12. Keyboard tray for LCD holder Max load 5 kg. 480 x 260 860 941-49
13. LCD holder with double arm Max load 15 kg. 930 49 002P
14. Pull-out steel shelf Mounting under the bench top. Free space for printer 400 x 500 x 510 x 515 PSP50
for printer 500 x 415 mm. Pull-ot extent 500 mm. Max load 35 kg.

Treston Packing Benches 7
