Page 9 - Treston

Spacemisers for storage bin cabinets

1 x spacemiser 16-300 1 x spacemiser 16-400
8 x storage bin cabinets 0830 8 x storage bin cabinets 1640
8 x storage bin cabinets 1630 8 x storage bin cabinets 0840

A free-standing spacemiser storage system for stores, production facilities, workshops and warehouses. The
spacemiser offers storage for 16 visible storage cabinets. The sturdy, ball-bearing base has a load capacity of 800
kg. These assemblies offer storage for up to 1792 different items on a floor area of only 0.64sqm. Easy to assemble
— no tools required.

Spacemiser 16-300 Retaining bars A 400

This assembly holds 16 storage bin cabinets from series Storage bin cabinets are also suitable for use in maintenance
300, which must be ordered separately. The unit includes a vehicles. Retaining bars, to be ordered separately as an
ball-bearing base and shelves in four layers. The assembly accessory, keep the bins in place in a moving vehicle.
is made of grey powder-coated steel (RAL 7035). One set includes 4 pieces. Retaining bars are suitable for
models 0830, 1630, 0840 and 1640.
• The overall dimensions of a completely assembled unit,
W x D x H: 700 x 700 x1680 mm.

• Load capacity 800 kg.

Spacemiser 16-400 1 x retaining bars A 400
1 x storage bin cabinets 1640-5
This assembly holds 16 storage bin cabinets from series
400, which must be ordered separately. The unit includes a Treston Storage systems
ball-bearing base and shelves in four layers. The assembly
is made of grey powder-coated steel (RAL 7035).

• The overall dimensions of a completely assembled unit,
W x D x H: 800 x 800 x1680 mm.

• Load capacity 800 kg.

9
