High density storage cabinets

High density storage bin cabinets

High density storage cabinets are suitable for the
organisation and sorting of large item quantities at production
facilities, warehouses, stores and workshops. One cabinet can offer
storage for 336 separate items on a floor area of only 0.25 m². If necessary, the
cabinets can be equipped with castors or retaining bars.

This product includes a frame, bins and labels with protective shields. Backstops hold the bins when fully extended. Adjustable
feet are provided for fine levelling of the cabinet on uneven surfaces. The load capacity of a cabinet is 240 kg, and that
of a single shelf is 30 kg. The frame is made of grey powder-coated steel (RAL 7035). Profiled ends and a welded steel
construction contribute to the general robustness of the frame. Details on the shelf bins can be found on pages 12 and 13.

Code Grey Red Blue Grey Red Blue

Includes drawers 2440-3 2440-5 2440-6 4840-3 4840-5 4840-6
(type/quantity) 4020 4020 4020 4010 4010 4010
(24 pcs) (24 pcs) (24 pcs) (48 pcs) (48 pcs) (48 pcs)
Frame depth
width 410 410 410 410 410 410
height 605 605 605 605 605 605
870 870 870 870 870 870
Cross dividers, ordered
separately D-20 D-20 D-20 D-10 D-10 D-10
(quantity/drawer) (6 pcs) (6 pcs) (6 pcs) (6 pcs) (6 pcs) (6 pcs)

1010 Treston Storage systems
