Castor set PS-LH Retaining bars A-605

Includes 4 castors Ø 100 mm, 2 with brakes, and the Storage bin cabinets are also suitable for use in
required fittings. The load capacity of castors is 150 kg. maintenance vehicles and vessels. Retaining bars keep the
The overall dimensions of a cabinet on castors are (W x D bins in place in a mobile application. One set includes 8
x H): 605 x 410 x 980 mm. pieces. Note! High density storage bin cabinets have no
ready-made mounting holes on the back.

Storage bins 1

1. Storage bins from recycled plastic

Particularly suitable for in-house material flows
within factories and warehouses. Material: recycled
polypropylene (PP). Standard colour: grey RAL 7023.

2. Containers 2

Robust containers which meet the stringent requirements 3
for transport and warehousing. They have integral
handles and stack securely together. The straight sides
allow an economical use of space. Material: recycled
polypropylene (PP). Standard colour: grey RAL 7023.

3. Picking bins 4. Bin rail 700

All of the inner faces are rounded and the front has a A wall mounting rail for stacking and picking bins. With
distinctive sloping design which facilitates picking. Bins can fixing screws. The load capacity is 50 kg. Length 700 mm.
be hung on the wall on bin rails, or mounted on workbench Made of grey epoxy enamelled steel profile. Code 700.
bin rails. Material: polystyrene (PS). Standard colour: blue
RAL 5015.

Code Colour External dimensions Internal dimensions Capacity, Quantity/ 4
1 1949-30R Grey W x D x H mm W x D x H mm litres package

185 x 490 x 250 145 x 430 x 195 12.1 12

3149-30R Grey 310 x 490 x 250 270 x 430 x 195 22.6 12

2 10-18L-30R Grey 323 x 535 x 150 300 x 480 x 145 18.0 4

10-36L-30R Grey 323 x 508 x 280 300 x 480 x 270 36.0 3

3 30-1L-6 Blue 99 x 160 x 70 85 x 100 x 62 1.1 60

30-2L-6 Blue 198 x 160 x 70 175 x 100 x 62 2.2 30

30-23L-6 Blue 198 x 160 x 70 175 x 100 x 62 2.2 30
(2 fixed dividers)

4 700 Grey length 700

Treston Storage systems 11
