WIRE STRIPPERS

KNIPEX MultiStrip 10
12
Automatic Insulation Stripper 42

Stripping without re-adjustment from 0.03 to 10 mm²
7PKXGTUCN DNCFG IGQOGVT[ s TQDWUV CPF OQTG FWTCDNG
Ideal grip design with excellent haptics
Recessed wire cutter
> fully automatic adjustment to all single , multi and fine stranded
conductors with PVC insulation and a number of special insulation 12 42 195
throughout the entire capacity range from 0 03 to 10 mm²

> no manual fine adjustment necessary, no damage to the conductors
> the clamping jaws made of steel hold the cable in a way that
prevents slipping without damaging the remaining insulation
> with recessed wire cutter for copper and aluminium conductors,
multi stranded up to 10 mm² and single stranded up to 6 mm²
> particularly smooth running mechanics and very low weight
> replaceable blades block and length stop
> handle with soft plastic zone for a steady grip
> body: plastic, fibreglass reinforced
> blade: special tool steel, oil hardened

Patented mechanics

The incision depth of the stripping blade adjusts fully
automatically to the diameter of the wire and accordingly also
to the thickness of all standard insulating materials. There is
no need for any manual adjustment which is still necessary
YJGP QVJGT EQPXGPVKQPCN RNKGTU YKVJ C YKFG YKTG UVTKRRKPI
range are used.

Wire cutter for multiple stranded wire Steel clamping jaws avoid skidding of the
cables up to 10 mm² cable

Mode of operation of straight
STRAIGHT BLADE
cutters
An incision is made in the red
area only
Not suitable for highly flexible or
armoured insulation materials or
for multi layered insulation

Precise stripping from 0 03 to 10 mm² without re adjustment

MultiStrip Product video

0,03 mm 2 10 mm 2

EAN Stripping capacities
Article No 003773 mm mm² AWG g
12 42 195 05 580 195 0 03 10 32 7 136
12 49 21 057581 Spare blades block for 12 2 195
12 49 23 05760 Spare length stop for 12 2 195
