ELECTRONICS PLIERS

Electronics Diagonal Cutters
with inserted carbide metal cutting edges 77
DIN ISO 9654 H

> for extreme demands on cutting pliers caused by hard or tough
materials, e g piano, nickel, tungsten and diode wire, such as those
used more frequently in the electronics and aerospace industries
> always the right cutting tool, even with the hardest material
77 02 120 H
> precision carbide metal cutting edges soldered into forged blanks

> sturdy, zero backlash box joint
> hardness of the carbide cutting edges 80 83 HRC
> pliers with carbide metal cutting edges have a substantially longer
service life than such with conventional cutting edges
> constantly reliable cutting results due to the avoidance of cutter
deformations
> high cost saving due to longer service life of the pliers

77 02 120 H / 77 02 135 H / ESD 77 02 135 H
round head, with bevel
77 32 120 H / ESD
pointed head with chamfer,
with smal bevel

77 32 120 H ESD

Inserted carbide metal cutting edges
Precision carbide metal cutting edges
soldered into forged blanks

Cutting capacities Dimensions
EAN $ A D
Article No 003773 mm Head Handles Ø mm Ø mm Ø mm Ø mm mm mm mm g
77 02 120 H 075783 120 with multi component 2 0 1 1 0 0 6 1 11 7 5 85
mirror polished
77 02 120 H ESD 075813 120 grips 2 0 1 1 0 0 6 1 11 7 5 85
77 02 135 H 075806 135 with multi component 2 2 1 6 1 2 0 8 18 15 9 5 115
77 02 135 H ESD 075837 135 mirror polished grips 2 2 1 6 1 2 0 8 18 15 9 5 115
77 32 120 H 075790 120 mirror polished with multi component 1 6 1 0 0 6 0 2 1 11 7 5 80
77 32 120 H ESD 075820 120 grips 1 6 1 0 0 6 0 2 1 11 7 80
241
