Page 376 - KNIPEX katalógus
P. 376
INSULATED TOOLS
Diagonal Insulation Stripper
IEC 60900 DIN EN 60900 14
With long cutting edges
*KIJ EWVVKPI ECRCEKV[ FWG VQ JKIJ NGXGTCIG LQKPV
> precision stripping holes for single conductors of 1 5 and 2 5 mm²
> convenient cutting of NYM cables up to 5 x 2 5 mm²
> long tips for ultra fine cutting work also in confined areas 14 26 160
> induction hardened precision blades,
cutting edge hardness approx 60 HRC
> Vanadium steel, forged, multi stage oil hardened
Cutting capacities
EAN Stripping capacities
Article No 003773 mm Pliers Handles mm² AWG Ø mm Ø mm g
chrome insulated with multi component
14 26 160 0 0279 160 plated grips, VDE tested 1 5 2 5 15 13 2 5 1 5 216
Round Nose Pliers
DIN ISO 5745 IEC 60900 DIN EN 60900 22
> for bending wire loops
> precision ground, short, round jaws
> smooth tips
> Chrome vanadium electric steel, forged, oil hardened
22 06 160
Dimensions
EAN L3 W3 D1 T1
Article No 003773 mm Pliers Handles mm mm mm mm g
22 06 160 033790 160 chrome plated insulated with multi component grips, VDE tested 30 0 18 0 3 0 9 5 175
199
