CABLE AND WIRE ROPE SHEARS

Cable Shears
(ratchet action) 95
with telescopic handles 32

Cable shears with adjustable telescopic handles allowing
angular positioning
> for cable diameters up to 38 mm, handles can be positioned
at an angle to set the optimum handle width, which makes the 95 32 038
shear also suitable for work in confined areas
> comfortable work thanks to ratchet action and low weight
> heavy duty telescopic handles made of oval aluminium tubing;
extendable up to 770 mm for maximum leverage on large cable
diameters; retractable down to 570 mm for minimum space
requirements during transport
> replaceable cutting head
> extensive cutting range up to max Ø 38 mm or max 280 mm²
(e g x 70 mm² NYY) in copper and aluminium cables
> easier, neater cut due to optimised cutting edge geometry
Handles adjustable in length and angular position for easier work:
> adjustable bolted joint
UGV VJG JCPFNG NGPIVJ VQ VJG QRVKOWO NGXGT HQT RQYGTHWN EWVVKPI
> cutting head: special quality high grade tool steel, oil hardened
put the handles at an angle for a comfortable gripping position
> handles: high strength oval aluminium tubing
Cutting capacities
EAN
Article No 003773 mm Head Handles Ø mm mm² MCM g
95 32 038 071556 570 burnished with multi component grips 38 280 550 1980
95 39 038 073260 Spare cutter head for 95 32 038

Cable Cutters
(ratchet action) 95
with telescopic handles 32

> for copper and aluminium single conductors as well as multiple
stranded cables – also with hard rubber or plastic sheath
> not suitable for steel wire and wire ropes
> also suitable for cables with iron sheath reinforcement
> little hand force required for cutting due to optimum
transmission ratio
> high cutting capacity due to two hand operation and ratchet action
> the blade can be opened in any cutting position
> blade: special quality high grade tool steel, oil hardened
95 32 060
> handles: high strength oval aluminium tubing

> handle length with multiple position adjustment from
00 610 mm (short transport length, individual adaptation
to working conditions)

95 32 060
tool length: 600 810 mm; weight only 3820 g
95 32 100
tool length: 650 860 mm; weight only 980 g

Cutting capacities
EAN
Article No 003773 mm Head Handles Ø mm mm² MCM g
95 32 060 071563 600 60 7 0 1 00 3820
burnished with multi component grips
95 32 100 071570 650 100 960 1900 980
95 39 720 025290 Movable spare blade for 95 31 720 / 95 32 060 (ratchet action)
95 39 870 025306 Movable spare blade for 95 31 870 / 95 32 100 (ratchet action)
