Page 304 - KNIPEX katalógus

CABLE AND WIRE ROPE SHEARS

Bowden Cable Cutter 95 > for $owden cables and soft wire rope up to 3 0 mm dia (also V2A)
6 > smooth and clean cutting due to special shape of the cutting edges
> sickle shape cutting edges surround the material and prevent the wire
rope fanning out
> little handforce required due to very high transmission ratio
> with opening spring and locking device
> cutting edges additionally induction hardened
> High grade special tool steel, forged, multi stage oil hardened

95 61 150

Cutting capacities
EAN
Article No 003773 mm Shears Head Handles Ø mm g
95 61 150 065197 150 black atramentized polished plastic coated 3 0 205

Wire Rope and ACSR-Cable Cutters 95

> for wire ropes and steel rods, copper and aluminium cables
> suitable for cutting overhead cables with strain relief wire
(ACSR cables)
> angular cutting blades allow cutting of single rope wire
> optimum transmission ratio for high cutting performance 95 71 600

> bolted cutter head, replaceable low weight
> cutter head: high grade special tool steel, oil hardened
> handles: aluminium, high strength

95 77 600

95 81 600
with reinforced cutter head for higher performance, also cuts piano wire

Cutting capacities
EAN
Article No 003773 mm Head Handles mm² Ø mm Ø mm Ø mm AWG g
95 71 445 01 522 5 polished with plastic grips 95 10 0 7 0 3/0 1083
95 71 600 01 539 600 polished with plastic grips 150 1 0 9 0 5/0 1716
95 77 600 025313 600 polished with dipped insulation 150 1 0 9 0 5/0 2359
95 81 600 0253 600 polished with plastic grips 150 16 0 10 0 5 5/0 2256
95 79 445 025320 Spare cutter head for 95 71 5
95 79 600 025337 Spare cutter head for 95 71 600 / 95 77 600
95 89 600 025351 Spare cutter head for 95 81 600
163
