CUTTING PLIERS
Diagonal Cutters
for electromechanics
DIN ISO 5749 76
> with sharp, precisely aligned cutting edges for soft,
hard wire and piano wire
> cutting edges additionally induction hardened, 76 01 125
cutting edge hardness approx 63 HRC
> lap joint
> Vanadium electric steel, forged, multi stage oil hardened
76 12 125
low friction double spring for gentle and even opening
76 22 125
without bevel for flush cutting of soft wires;
low friction double spring for gentle and even opening
76 81 125
particularly tapered head with small bevel for work in confined areas 76 05 125
(cable harnesses, multiple stranded wires)
Cutting capacities Dimensions
EAN A $ D
Article No 003773 mm Pliers Head Handles Ø mm Ø mm Ø mm Ø mm mm mm mm g
black
76 01 125 018 90 125 polished plastic coated 0 3 0 2 3 1 5 0 6 1 5 16 9 90
atramentized
76 03 125 018506 125 chrome plated plastic coated 0 2 5 1 8 1 0 0 6 1 5 16 9 90
76 05 125 005315 125 chrome plated with multi component grips 0 2 5 1 8 1 0 0 6 1 5 16 9 118
black
76 12 125 0 8015 125 atramentized polished with multi component grips 0 2 5 1 8 1 0 0 6 1 5 16 9 112
black
76 22 125 0 8022 125 polished with multi component grips 0 2 5 1 5 16 9 107
atramentized
black
76 81 125 0185 125 atramentized polished plastic coated 0 1 7 1 3 0 8 1 5 16 9 87
