Page 168 - KNIPEX katalógus

CUTTING PLIERS

Diagonal Cutters
DIN ISO 5749 70

The next generation of the KNIPEX classic,
with even better features:
JKIJGT EWVVKPI HQTEG VJCP VJG RTGXKQWU OQFGN
plus longer cutting edges
70 01 160
High cutting force due to optimum cutting geometry
and transmission ratio

> strong precison rivet for even movement and long service life
> high precision cutting edges: additionally induction hardened,
cutting edge hardness approx 62 HRC
> narrow head with long cutting edges:
good access also in confined areas
> long tool life and high loading capacity 70 02 160
> the essential diagonal cutters for diverse use
> Vanadium steel, forged, multi stage oil hardened

70 05 160 T*
Pliers with tether attachment point for mounting a fall protection

70 05 160

70 05 160 T

70 06 160

70 07 160
Cuts thin Cu wire accurately, also at the cutting edge tips

Cutting capacities
EAN
Article No 003773 mm Pliers Head Handles Ø mm Ø mm Ø mm g
black
70 01 160 013 26 160 polished plastic coated 0 3 0 2 0 171
atramentized
black
70 02 160 03 032 160 with multi component grips 0 3 0 2 0 206
atramentized
70 05 160 039600 160 chrome plated with multi component grips 0 3 0 2 0 207
with multi component grips and
70 05 160 T 080022 160 chrome plated 0 3 0 2 0 207
integrated tether attachment point
insulated with multi component
70 06 160 021995 160 chrome plated 0 3 0 2 0 216
grips, VDE tested
70 07 160 018155 160 chrome plated with dipped insulation, VDE tested 0 3 0 2 0 227
insulated with multi component
70 26 160 018223 160 chrome plated grips, VDE tested 0 216
* Other tools with tethering can be found from page 25 ff 95
