Forming pliers
Forming pliers for passive components
120 mm/ 4.724 Inch Suitable for secure assembly.
70 g / 2.47 oz. Forms the two opposing Us in one operation.
A = jaw length
D = height of tips
E = width of tips
F = length of forming tool
Model Dimensions in mm/Inch Max. connection diameter
A D E F Diodes Capacitors Resistors
554TX 20 6.5 6.5 4 0.65 mm 0.7 mm 1 / W
2
.787 .256 .256 .157 .025 Inch .027 Inch
120 mm/ 4.724 Inch For cutting and bending components into two
67 g / 2.36 oz. operations to a predefined length.
A = jaw length
D = height of tips
E = width of tips
F = length of forming tool
Model Dimensions in mm/Inch Max. connection diameter
A E F Diodes Capacitors Resistors
50788 23 4 3 0.65 mm 0.7 mm 1 / W
2
.905 .157 .118 .025 Inch .027 Inch
120 mm/ 4.724 Inch For cutting and bending different types of
67 g / 2.36 oz. components with two outputs.
A = jaw length
D = height of tips
E = width of tips
F = length of forming tool
Model Dimensions in mm/Inch Max. connection diameter
A D E Diodes Capacitors Resistors
50789Z 23 3.3 3.5 0.65 mm 0.7 mm 1 / W
2
.905 .130 .138 .025 Inch .027 Inch
