SX45

Greenough Stereo Microscope

Designed as an affordable stereo zoom Affordable stereo zoom microscope with first-class performance
microscope, the SX45 with its long working x8 – x50* (6.3:1 zoom ratio) click-stop stereo zoom
distance, precision optics and compact magnification (x200 max.)

design is the perfect solution to many Wide range of options and configurations
Extra long working distance (115mm*)
industrial and biological applications. A
wide array of optional accessories allows for * with standard x1.0 objective
further tailoring to individual requirements.

Options
With more than 50 years experience in design and manufacture of
high performance optical systems, Vision Engineering’s SX45 Image Capture & Archive
delivers value, performance and flexibility. Trinocular head option permits the use of digital / video
camera.
Multimedia solutions are available for image archiving,
SX45 Overview acquisition, analysis and documentation.
The SX45 provides high quality stereo viewing, ideal for both
LED Ringlight
industry and life sciences, with an extra-long working distance
For use with bench stand models, where additional surface
for assembly, manipulation, re-work, dissection, or simple illumination is required (required option with boom mount
variants).
inspection tasks. Additionally, a wide range of stand options and
accessories allow tailoring to suit individual requirements.
Floating Stage
Optical Performance For use with bench stand models, the floating stage pro-
vides smooth sample control, ideal for inspection tasks.
Precision optics deliver high resolution, flat field and high
contrast images with long working distances and large
depth of field Polarisation Set
22mm Field Number (standard) eyepieces with eyepiece Polarising filters can be accommodated with bench stand configurations.
dioptre setting
Interpupillary distance adjustment (52 to 75mm)
Eyepieces Objective Lens Zoom Range Working Distance
x10/22 F.N. x0.5* x4 - x25 220.6mm
x10/22 F.N. x1.0 x8 - x50 115.0mm
x10/22 F.N. x2.0 x16 - x100 57.5mm
x15/16 F.N. x0.5* x6 - x37.5 220.6mm
x15/16 F.N. x1.0 x12 - x75 115.0mm
x15/16 F.N. x2.0 x24 - x150 57.5mm
x20/13 F.N. x0.5* x8 - x50 220.6mm
x20/13 F.N. x1.0 x16 - x100 115.0mm
x20/13 F.N. x2.0 x32 - x200 57.5mm
* stand extension required when using x0.5 objective lens with bench stand model to accommodate
increased working distance.
