Side Cutters and Tip Cutters | Pneumatic side cutter and tip cutter

Side cutters - tapered head cutting head for 1500 BSF

Ÿ The edges of the cutter head are
straight and taper to a point, allowing
access to hard to reach area.
1.16 oz. / 35 g

Model Cut A B C Max. cutting capacity in mm
Inch mm Inch mm Inch mm Copper
wire
1522NA 0.354 9 0.413 10.5 0.24 6 Ø 1,4
Flush

Pointed relieved head for 1500 BSF

Ÿ This is the narrowest head shape.
Ÿ The underside is relieved and
facilitates optimum access even to
1.12 oz. / 32 g extremely hard-to-reach areas.

Model Cut A B C Max. cutting capacity in mm
Inch mm Inch mm Inch mm Copper
wire
1522NB 0.354 9 0.413 10.5 0.24 6 Ø 1,2
Flush

Cutting head for 1500 BSF - tip cutter - angled head

Ÿ The angled head provides for precise
cuts at different working angles.
1.34 oz. / 38 g
30°

Model Cut A B C Max. cutting capacity in mm
Inch mm Inch mm Inch mm Copper
wire
1503E 0.472 12 0.413 10.5 0.24 6 Ø 1,2
Flush

334 Precision Tools
