Electronic screwdriver | Screwdriver Inserts

Screwdriver Inserts

Phillips -Bits
®
Power unit

1/4" Hex Insert Bits-
Limited Clearance

Order no. Size Overall length Turned length (A) Turned OD (B)
Inch mm Inch mm Inch mm
446-0X 0 1 25 7/16 11 0.108 4.06
446-1X 1 1 25 7/16 11 0.108 4.06
446-2X 2 1 25 7/16 11 0.108 4.06

Electric screwdriver
Pozidriv Bits
®

1/4" Hex Insert Bits

Order no. Size Overall length Turned length (A) Turned OD (B)
Inch mm Inch mm Inch mm
440-1-PZDX 1 1 25
440-2-PZDX 2 1 25
440-215-PZDX 2 1 1/2 38
440-22-PZDX 2 2 51
440-3-PZDX 3 1 25
440-4-PZDX 4 1 1/4 32
446-1-PZDX 1 1 25 7/16 11 0.18 4.6 Accessories
446-2-PZDX 2 1 25 7/16 11 0.18 4.6

Slotted Bits

1/4“ Hex Insert Bits -
Limited Clearance

Order no. Screw size Lenght Blade Thickness (A) Blade Width / Body
Inch mm Inch mm Inch mm
445-000X 1F-2R 0.984 25 0.021 0.53 0.125 3.2
445-00X 2F-3R 0.984 25 0.025 0.64 0.140 3.6 Screwdriver inserts
445-0X 3F-4R 0.984 25 0.030 0.76 0.154 3.9
445-10X 4F-5R 0.984 25 0.034 0.86 0.185 4.7
445-20X 5F-6R 0.984 25 0.036 0.91 0.216 5.5
445-30X 6F-7R 0.984 25 0.038 0.97 0.248 6.3

Electronic screwdriver 301
