Electrostatic Charging

Chargemaster VCM TM

Simco-Ion’s Chargemaster VCM is programmable for Speci cations
either voltage or current control mode to supply the
high voltage for charging bars and various charging Input Voltage 85-264 VAC @ 47-63 Hz (self adjusting)
applicators used to electrostatically bond materials. The Output Voltage 0-30 kV @ 5 mA; 0-60 kV @ 2.5 mA
Chargemaster VCM provides a simple and economical Voltage Rise Time Under 70 msec
solution for a wide range of production processes Output Ports 4
maximizing the e ciency of the application.
Remote I/O Analog Signals: 0-20/4-20 mA or 0-5/0-10 VDC via D/sub connector
The VCM is available in three versions; negative output Remote On/O via D/sub connector and programmable menu
voltage, positive output voltage and outputs of both Temperature 32-131°F (0-55°C)
positive and negative polarities (Bi-Polar).
Enclosure Steel
• Run up to four charging bars or applicators Dimensions 30 kV: 10.5”W x 4.25”H x 13.5”D; 60 kV: 10.5”W x 4.25”H x 15”D
• Capable of voltage or current control mode
operation Weight 16.5 lbs
• Simple programming and setup Certi cations
• Remote operation capability
• Short circuit protected output with status indicators
• Powerful industry leading 5 mA pinning current

Bi-Polar (VCM-BP) Wall mount

MCM 30 TM

The MCM 30 is a powerful high Speci cations
e ciency charging generator
that supplies high voltage for Input Power 24 VDC, 3A, 75W (max)
charging bars and various charging Output Power 3-30 kVDC; 0.1-1 mA (single output)
applicators. The MCM 30 packs a Temperature 32-104°F (0-40°C)
punch in a small size and provides Interface Connections (12) position Terminal block and multi-purpose interface connector
simple and economical solutions Mounting Integrated mounting brackets
for a wide range of production
processes. Enclosure ABS Plastic (UL94V-0), color: black
Dimensions 7.75”L x 3.00”W x 2.62”D (197L x 76W x 67D mm)
Weight 1.7 lb (0.77 kg)
