Ionizing Air Nozzles

IQ Power Nozzle
TM

Simco-Ion’s IQ Power Nozzle is a shockless pulse DC ionizer engineered to operate at
7 kV and is compatible with the IQ Power Static Neutralizing System. Can be used with
the IQ Power BPS and MPS power supplies. IQ Power Nozzle users have worry free,
continuous active monitoring. Choose between High E ciency con guration for most
applications or Slotted for applications that require a high amount of air.
IP66 RATED
• Flexible installation allows multiple nozzles to be positioned on a single wire run
• Continuous monitoring of performance and status
• IP-66 rated against particulate and splash High voltage cables sold separately in 10, 20,
30 ft. lengths, which can be cut to the exact
• Communicates with the control station requirements of your application.

Speci cations
Input Voltage 7 kVDC (IQ Power speed mode) using speci ed HV cable GREAT FOR MOST GREAT FOR
APPLICATIONS AIR RINSING
Air Input 80 psi (max)
Air Input Connection 1/8 NPT straight of right angle for use with ¼” O.D. tubing
Air Consumption 10 scfm @ 30 psi; high e ciency 1.5 scfm @ 30 psi
Temperature 60°C (140°F) max
Dimensions 2.1”L x 2.1”W x 1.3”H (individual nozzle)
IP Rating IP-66
High E ciency Con guration Slotted Con guration

Ioncell TM

Simco-Ion’s Ioncell In-line Ionizer enables stunning performance in longer-
length delivery lines by overcoming traditional ion recombination limitations;
enabling focused ionized air to be delivered to previously inaccessible locations.
• Compact design that pipes ions through long tubes
• Various output attachments available
• Powered by low voltage power supply or through 24 VDC input
• Can daisy-chain up to 6 units

Speci cations
Input Voltage 24 VDC
Balance +/-50V
Air Pressure 50 psi (max)
Emitters Tungsten
Connectors 4 position modular; DC power IN
Indicators Green-Power On; Red-fault indicator (TTL level alarm output) Ring Output Applicator
Temperature 32-122˚F (0-50˚C)
Dimensions 2.5”H x 1.3”W x 4.5”L (64 x 33 x 115 mm)

Split Tube

Single Tube
Output Tube Con guration Air Knife Output Applicator

7
