ESD accessories for TPH




           Non ESD sertified accessories on page 46.





         Metal shelf TH
         Size       Max        Suitable for    Code ESD
         W x D mm   load kg
         1119 x 145  30        TPH712          TH120 ESD
         1419 x 145  30        TPH715/ 915     TH150 ESD
         1719 x 145  30        TPH718/ 918     TH180 ESD
         Adjustment for depth, height and angle. For stacking and picking bins. Load
         capacity 30 kg.                                      Metal shelf TH



         Bin profile BP
         Width mm  Max load kg  Suitable for   Code ESD
         profile 1115  15      TPH712          BP120 ESD
         profile 1415  15      TPH715/ 915     BP150 ESD
         profile 1715  15      TPH718/ 918     BP180 ESD
         Aluminium profile for stacking and picking bins.
                                                              Bin profile BP



         Auxiliary steel shelf ASSA
         Size W x D x H mm  Suitable for       Code ESD
         217 x 298 x 20   BP                   ASSA4
         159 x 254 x 50   BP                   ASSA5
         Shelf for A4/A5 paper and tape dispensers (max 2 pcs per shelf). Mounted
         on bin profile. Max load 3 kg.
                                                              Auxiliary steel shelf ASSA



         Auxiliary shelf SH
         Size W x D mm  Max load kg  Suitable for  Code ESD
         1200 x 310  50        TPH712          SH120 ESD
         1500 x 310  50        TPH715/ 915     SH150 ESD
         1800 x 310  50        TPH718/ 918     SH180 ESD
         Height adjustable shelf. 25 mm laminated particle board .

                                                              Auxiliary shelf SH


         Backstop LIST
         Size W x D x H mm     Suitable for    Code ESD
         1400 x 52 x 27        AT 150TPH, SH150  LIST150
         1700 x 52 x 27        AT 180TPH, SH180  LIST180
         Prevents items from falling off the shelf. Can be fixed on the lower shelf AT or
         on the shelf ALH.
                                                              Backstop LIST




         Lower steel shelf LSS
         Size W x D  mm  Max load kg  Suitable for  Code ESD
         1418 x 460  30        TPH715/ 915     LSS150
         1718 x 460  30        TPH718/ 918     LSS180
         Hangs on the horizontal bars. Can be equipped with steplessly adjustable low
         M-divider hoops (4 pcs/set, code LDH).
                                                              Lower steel shelf LSS
