P. 46

Non ESD sertified accessories










             !    All non ESD sertified accessories are EPA –compatible when their combination of the potential charge level and
                  physical distance to the ESDS –related parts is managed by ESD standard IEC 61340-5-1




         Adapter set AS
         Name                                  Suitable for      Code
                                               MH / MA / MA2     AS2
         Adapter set for upright profiles*
                                               MA3               AS3
         * Adapter sets AS are only needed for Concept, TED, TP and TPH benches with uprights/C-profiles. Adapters
         are not required for WB benches with AL2X uprights.





         LCD bracket MH                                                          Adapter set AS2   Adapter set AS3
         Name               Max load kg  Suitable for            Code
         LCD bracket MH     15        Concept, TED, TP, TPH, WB  MH
         The quick-release mechanism is equipped with the standard used flat-screen mount 75 x 75 and 100 x 100 for
         the mounting of all normal flat-screens. Adapter set AS2 is needed for mounting LCD bracket MH to Con-
         cept, TED, TP and TPH benches, ordered separately.





         LCD swivel arm MA                                                       LCD bracket MH
         Name               Max load kg  Suitable for            Code
         LCD swivel arm MA  10        Concept, TED, TP, TPH, WB  MA
         The quick-release mechanism is equipped with the standard flat-screen mount 75 x 75 and 100 x 100 for the
         mounting of all normal flat-screens. The arm is double articulated, turns through a radius of 180° and will extend
         between 95-425 mm from the upright. Adapter set AS2 is needed for mounting LCD swivel arm MA to Con-
         cept, TED, TP and TPH benches, ordered separately.





                                                                                 LCD swivel arm MA
         LCD swivel arm MA2
         Name               Max load kg  Suitable for            Code
         LCD swivel arm MA2  15       Concept, TED, TP, TPH, WB  MA2
         The quick-release mechanism is equipped with the standard, widely used flat-screen mount 75 x 75 and 100 x
         100 for the mounting of all normal flat-screens. The arm is double articulated, turns through a radius of 180° and
         will extend between 95-425 mm from the upright. Adapter set AS2 is needed for mounting LCD swivel arm
         MA2 to Concept, TED, TP and TPH benches, ordered separately.



                                                                                 LCD swivel arm MA2

         LCD screen holder with height adjustable arm MA3
         Name               Max load kg  Suitable for            Code
         LCD screen holder MA3  3-8   Concept, TED, TP, TPH, WB  MA3
         Highly ergonomic and easily height adjustable monitor arm with a gas spring. Easy mounting of the monitor with
         a quick-release mechanism, standard flat screen mount 75 x 75 mm and 100 x100 mm  for LCD screens. Cable
         management by cable clips, 2 pcs included. The double arm turns through a radius of 180 and will extend between
         65–515 mm from the upright. Adapter set AS3 is needed for mounting LCD swivel arm MA3 to Concept,
         TED, TP and TPH benches, ordered separately.
                                                                                 LCD screen holder MA3
