P. 34

ACCESSORIES Concept, TED and TP



         Auxiliary top, fixed brackets
         Name              Size W x D mm  Max load kg    Code ESD
         Auxiliary top left  400 x 500  40               926 49 001P
         Auxiliary top right  400 x 500  40              926 49 002P
                                                                            Auxiliary top

         Bottle holder
         Name                                            Code ESD
         Bottle holder (Ø 100) for upright tube          859 063-49


                                                                            Bottle holder
         Roll holder for upright tube
         Name                                            Code ESD
         Roll holder for upright tube  (roll ø height 150 mm, width 320 mm)   860 841-49




                                                                             Roll holder
        Cable management




         Cable ducts
         Name      Size W x H mm  Suitable for module  Code ESD
         Cable duct  467 x 360  M500           860 808-49
         Cable duct  717 x 360  M750           860 044-49
         Cable duct  870 x 360  M900           860 045-49
         Suitable only for Concept bench. Fitted to upright tube.
         Cable ducts hide the untidy cables from other equipment. This makes it easy to
         keep the back of the workstation and its surroundings tidy.  Hide wires and cables with a cable duct.


         Horizontal cable troughs
         Name             Size        Suitable   Code ESD
                          W x D x H mm  for module
         Horizontal cable trough  737 x 97 x 45  M750  854 553-49
         Horizontal cable trough  890 x 97 x 45  M900  854 554-49
         Horizontal cable trough   1187 x 97 x 45  M1200  854 555-49
         Horizontal cable trough   1337 x 97 x 45  M1350  890 551-49
                                                              Fitted to upright tubes, the horizontal cable trough enables cables
         Horizontal cable trough   1487 x 97 x 45  M1500  854 556-49
                                                              to be hidden at the top of the workstation.
         Horizontal cable trough  1793 x 97 x 45  M1800  854 557-49
         Horizontal troughs effectively conceal the cables, without preventing
         maintenance access.
                                                                                 Vertical cable trough


         Vertical cable trough
         Name             Size W x D x H mm   Code ESD
         Vertical cable trough  52 x 62 x 1360  861 130-49
         The vertical cable trough is fitted on the side of the upright tube.



         Treston Cable Tidy
         Name           Size         Suitability  Code ESD
                        W x D x H mm
         Treston Cable Tidy  800 x 62 x 100  TED   TCT-49
         Treston cable tidy hides the cables below the worktop.
                                                              Treston Cable Tidy for TED
