WORKBENCHES TP

TP - ideal basic workbench

• Stepless height adjustment with allen key between
650-900 mm.

• Upright tubes (ordered separately) allow to attach a 650-900 mm
wide range of accessories.

TP workbench
Bench size W x D mm Max load kg Code ESD 500 / 700 / 700 / 1000 / 1200/ 1500 / 1800 mm
700 x 500 150 TP507 ESD 900 mm
1000 x 500 150 TP510 ESD
1500 x 500 150 TP515 ESD
1000 x 700 300 TP710 ESD
ESD bench top
1200 x 700 300 TP712 ESD
• Light grey laminate surface
1500 x 700 300 TP715 ESD
• Grey edging
1800 x 700 300 TP718 ESD
• Thickness 25 mm
1500 x 900 300 TP915 ESD
• Semi-conductive (ESD)
1800 x 900 300 TP918 ESD
Lower steel shelf LSS
Name Size Max Code ESD
W x D mm load kg
Lower shelf 1418 x 460 30 LSS150
Lower shelf 1718 x 460 30 LSS180
Low M-divider hoops 460 x 315 LDH
(4 pcs/set)
Hangs on the horizontal bars. Can be equipped with steplessly adjustable
low M-divider hoops.

The TP bench can be equipped with castors!
Castor set Ø100, code ESD 860 429 -00. Insert set (required to fit castors), code 853 289-00
Load capacity with castors 150 kg. We recommend using the fixing frame for the castors.

TP upright frame
Size W x H mm Max load kg Code ESD
M750 x 1500 300 123 49 005
M750 x 1850 300 123 49 006
M900 x 1500 300 123 49 007
M900 x 1850 300 123 49 008
1500 / 1850 mm 600 mm

Bench top & brackets for TP upright frame
Size W x D mm Max load kg Code ESD
1200 x 600 60 TT12060-ESD
Corner bracket pair 1200 mm

TP upright frame with bench top is a lighter version of the TP workbench. In
addition to the bench top attached to the frame, it can be equipped with any
of the Concept accessories. It’s ideal for lighter use, when some additional
workspace is needed. 830 mm

22 Treston - ESD workspaces
