WORKBENCHES TP

Designing TP workstation

• Select laminate or ESD version of the bench

• Equip with accessories. To equip TP with above-desk
accessories, select first the upright tubes. 650-900 mm

700 / 1000 / 1200/ 1500 / 1800 mm

TP workbench
500 / 700 / 900 mm
Bench size Max Code Code ESD
W x D mm load kg
700 x 500 150 TP507 TP507 ESD
1000 x 500 150 TP510 TP510 ESD Laminate bench top
1500 x 500 150 TP515 TP515 ESD
• 25 mm low pressure laminate
1000 x 700 300 TP710 TP710 ESD
• Light grey surface
1200 x 700 300 TP712 TP712 ESD
• Plastic edging
1500 x 700 300 TP715 TP715 ESD
1800 x 700 300 TP718 TP718 ESD
1500 x 900 300 TP915 TP915 ESD
1800 x 900 300 TP918 TP918 ESD
ESD bench top
• Light grey laminate surface
• Grey edging
1. Lower shelf for TP • Thickness 25 mm
Name Size Max Code • Semi-conductive (ESD)
W x D mm load kg
Lower shelf 1080 x 500 50 AT 120TPH
Lower shelf 1380 x 500 50 AT 150TPH
Lower shelf 1680 x 500 50 AT 180TPH
Not enough space above the workstation? Then utilise the space below. The
lower shelf for TP bench simply hangs on the horizontal bars.
1

2. Lower steel shelf LSS
Name Size Max Code
W x D mm load kg
Lower shelf 1418 x 460 30 LSS150
Lower shelf 1718 x 460 30 LSS180
Low M-divider hoops (4 pcs/set) 460 x 315 LDH
2
Hangs on the horizontal bars. Can be equipped with steplessly adjustable low
M-divider hoops.

3. Side worktop
Name Size Max Code
W x D mm load kg
Side worktop 400 x 700 35 TP704 ST 3
Side worktop 400 x 900 35 TP904 ST
Easy to fix to the legs of the bench. Can be fixed on the left or right side of the
bench and brackets placed either above or underneath. Height adjustable
575-900 mm from the floor.
