STORAGE SYSTEMS Shelves and cabinets

80/200-3 C 309 07 103
Qty Name Code
1 Cabinet frame 80/200 C 309 07 000
2 Drawer 80 854 346-49
2 Steel shelf 80 854 345-49
3 Shelf divider H 370/400 832 855-49
1 Perforated panel 736x 640 835 633-07
1 Extendable shelf 80 854 347-49
1 Pair of support feet 864 730-49
1 Pair of steel dividers 861 116-49
1 Drawer for suspension folders 854 348-49

When the cabinet is used
for storing folders,
a separate pull-out shelf is a good
idea. This shelf makes it easy to
browse through the folders.

Industrial cabinet with plexiglass doors
Name Size Max Code
W x D x H mm load kg
Cabinet frame 80/200, 800 x 425 x 2000 1000 C 309 07 000-TD
blue doors
Cabinet frame 80/200, 800 x 425 x 2000 1000 C 309 41 000-TD
grey doors
Cabinet 80/200 800 x 425 x 2000 1000* C 309 07 001-TD
with 4 shelves, blue doors
Cabinet 80/200 800 x 425 x 2000 1000* C 309 41 001-TD
with 4 shelves, grey doors
*100 kg / shelf

Computer cabinet
Computer cabinet protects equipment from dust and dirt, even
in the most demanding conditions. The computer cabinet is pres-
surised and equipped with an air filter that keeps the dust out. A
screen up to a maximum size of 26” will fit in the computer cabinet.

Name Size mm Code
Computer cabinet 800 x 500 x 1600 854 358-49
Computer cabinet 800 x 500 x 1600 854 364-49
(without the energy rail)
(Flush fitting handle not suitable)

Treston - For a better work environment 165
