P. 32

SNAPBOX

        Boxes for SMD components with sprung lid, four different sizes available, can be joined to each other by means of a dovetail assembly
        system. The lid is provided with a finger point for easy and quick opening, can remain in open posi on and closes automa cally



        thanks to spring loading. Black conduc ve version is normally available from stock, on request (minimum 100 pcs)  the colours: red,

        white, blue, yellow and green. All boxes can be supplied with the transparent cover.


                                                                 SIZE 1          SIZE 3
                                                                 SIZE 1
                                                                                 SIZE 3
                                                                                                 SIZE 4
                                                                                                 SIZ E 4
                                                                   SIZE 2
                                                                   SIZE 2






         7808.620 SNAPBOX1 ESD black
                                                                       SIZE 1
         7808.621 SNAPBOX1 ESD black, transparent cover            int.16x12x15mm
         7808.622 SNAPBOX1 not ESD various colours                  est.20x28x20mm
         7808.627 SNAPBOX1 not ESD various colours, transparent cover                          SIZE 1
         7808.632 SNAPBOX2 ESD black
                                                                       SIZE 2
         7808.633 SNAPBOX2 ESD black, transparent cover            int.37x12x15mm
         7808.634 SNAPBOX2 not ESD various colours                 est.40x28x20mm                        SIZE 2
         7808.635 SNAPBOX2 not ESD various colours, transparent cover
         7808.644 SNAPBOX3 ESD black                                                            SIZE 3
                                                                       SIZE 3
         7808.645 SNAPBOX3 ESD black, transparent cover            int.37x41x15mm
         7808.646 SNAPBOX3 not ESD various colours                 est.40x56x20mm
         7808.651 SNAPBOX3 not ESD various colours, transparent cover
         7808.656 SNAPBOX4 ESD black
                                                                       SIZE 4
         7808.657 SNAPBOX4 ESD black, transparent cover            int.57x68x15mm
         7808.658 SNAPBOX4 not ESD various colours                 est.60x84x20mm                          SIZE 4
         7808.663 SNAPBOX4 not ESD various colours, transparent cover
          SNAPBOXSET

         7808.686 Storage cabinet with 3 drawers H22 Black ESD
                  With 432 SNAPBOX1 (3 x 144) ESD transparent cover
         7808.687 Storage cabinet with 3 drawers H22 Black ESD
                  With 216 SNAPBOX2  (3 x 72) ESD transparent cover
         7808.688 Storage cabinet with 3 drawers H22 Black ESD
                  With 108 SNAPBOX3  (3 x 36) ESD transparent cover
         7808.689  Storage cabinet with 3 drawers H22 Black ESD                 7808.687
                  With 48 SNAPBOX4  (3 x 16) ESD transparent cover
         7805.153 Storage cabinet with 3 drawers MOD22 ext.267x355x105(H)mm
                  customizable with the choice of SNAPBOX1-2-3-4
        SMD -  VISTABOX

        VISTABOX zinc plated assembly stand can house in two shelves an

        assortment of SNAPBOX containers  with different sizes. The VISTABOX
        is especially suited for assembly and maintenance tables
        Material:zinc plated steel
        Dimensions: 180 x 260 x 200mm
        Capacity: 48 base units (size 1) for shelf
         7808.690 Assembly-stand, 2 trays for SNAPBOX (containers excluded)
