LABESERT 10 LABEFIX - PCB ASSEMBLY

Made in conduc ve polypropylene, LABESERT racks are suitable LABEFIX trays are used for component inser on before wave

for automa c PCB inser on machines. Channel pitch: 10mm soldering of the PCBs. A special foam gently holds the leads

Walls and terminal plates made by conduc ve plas c (60°C) un l the PCB is removed for wave soldering. The foam doesn’t

PCB adjustement: from 40 to 260mm crumble, or pollute and has a very long life.
Side Guide Slot: depth 3.5mm - width 7mm Material: zinc plated material base - conduc ve polyethylene

closed cell (cross linked foam density ISO 845 60Kg/m
3
thickness 7mm )
Weight: 1Kg
Standard tray 530x330x8mm with foam
(other dimensions on request)
Only foam 500x327x7mm

7804.110

7610.100

7610.100 Standard tray 530x330x8mm with foam
(other dimensions on request)
7804.110 LABESERT 10 Rack dim. 315x355x575(H)mm
7804.110R LABESERT 10R Rack dim. 315x355x575(H)mm 7610.110D Only foam 515x327x7mm

(with two lateral s ffening metal plate)
PCB ASSEMBLY FIXTURES A professional line of assembly jigs for PCB’s, designed to
simplify placing and soldering of electronic components.
PCSA1,2,4 are supplied with central and two sliding rails as

standards. Addi onal rails may be added to accommodate
a larger number of small boards.
The frame and lid assembly may be detached from the
moun ng base. A er moun ng the components on the

PCB’s , the foam back lid is a ached and closed, and the
whole assembly is li ed and rotated for soldering.

An ingenious design of the base permit an adjustable
working angle on both side of the PCB’s.
The jig is varnished steel, and the component pressing
PCSA2 foam is in conduc ve material.

PCSA1
7915.599 PCSA1 PCB’s holder, max. working dimensions 270 x 220mm
7915.601 PCSA2 PCB’s holder, max. working dimensions 500 x 220mm
7915.605 PCSA4 PCB’s holder, max. working dimensions 500 x 350mm
7915.610 Additional sliding rail for PCSA1
7915.612 Additional sliding rail for PCSA2 and PCSA4

7804.132
7804.134
LABETRAY - PCB HOLDERS

Made from black conduc ve polypropylene, LABETRAY have

mul ple uses in the sta c free environment, as holding the

PCBs during assembly, tes ng and rework.

7804.130 Conduc ve L-shaped LABETRAY dimensions: 208x272x93mm
7804.132 Conduc ve L-shaped LABETRAY dimensions: 355x268x128mm
7804.134 Conduc ve fl at LABETRAY - 25 slots dimensions: 490x180x50mm
