LABERACK - PCBS HANDLING

LABERACK is an adjustable frames that provides a secure method for
storage and handling of mounted PCBs or LABEFIX trays.
Material:Sta c dissipa ve polypropylene, Rs 10 ÷ 10 Ω
6
8

Sidewall dimensions: 480 x 290 x 35 mm.
Intermediate wall dimensions:470 x 280 x 40 mm.
Connec ng rail: sec on: 30 x 15 mm.

Number of storage channels: 79
Distance between channel centres: 5 mm.
Maximum PCB thickness: 2.3 mm max.
Channel depth: 4 mm.

Stainless-steel s ffening rib.
Bolts and screws included with sidewalls and intermediate walls.
To give the exact length of connec ng rail add to the board width 20 mm.

for each sidewall and 6 mm for intermediate wall
7804.007 Sidewall in black dissipa ve polypropylene +70°C
7804.017 Intermediate wall in black dissipa ve polypropylene +70°C
7804.002 Aluminium connec ng rail(length cut to max 3m)
7804.021 Handle for transport (rail fi xing)
7804.025 Bag of 40 spare screw and bolts
7804.040 Clips for sidewall (with labels)
(package of 100)
7804.041 Clips for intermediate wall (with labels)
(package of 100)

MINILABERACK DEPOPRINT
Safe storage and transport system for PCBs from assembly Made from black conduc ve polystyrene, the DEPOPRINT

through testing. Easy snap-together modular system to system accomodates various board dimensions throughout
increase storage capacity.The racks are made from black sta c storage, produc on and despatch. Fits plas c containers type

dissipa ve polypropylene Newbox or other 300x400 and 600x400mm standard Euro

Material: Sta c dissipa ve polypropylene, Rs 10 ÷10 Ω boxes. Two different sidewall sizes that slide along two parallel
8
5

Distance between channel centres: 6mm aluminium connec ng rails 95mm high (lenght cut to max 3m).

Maximum PCB thickness: 3.8mm Material: black conduc ve polystyrene

Channel depth: 3mm Rs: <10 Ω
5
Number of storage channels: 44 Temperature range: from 0 to +55 °C
Side wall: dimensions:300 x 170 x 21 mm Number of slots: 32

Connec ng rail: sec on 37 x 9 mm Distance between slot centres: 10 mm

Connec ng rails cut to length (max. 3m) Maximum thickness of the board: 2.3 mm

To give the exact length of connec ng rail add to the board Depth of the slots: 2.3 mm

width 18mm for each sidewall
7804.052 Sidewall black dissipa ve 7804.751 DEPOPRINT Sidewall 209 mm (H)
7804.060 Aluminium connec ng rail 7804.760 Aluminium Connec ng Rail 95x553 mm
7804.075 Bag of 40 spare nuts and bolts 7804.762 Aluminium Connec ng Rail 95x250 mm
7804.765 Aluminium Connec ng Rail 95 mm (H)
7804.759 Inser on Stop

Snap-on inser on of back-stop

Snap-on inser on for sidewall
