GROUNDING

PGT-61-164 SureTest® CIRCUIT ANALYZER PGT-6302QG OUTLET TESTER WITH QUBE & GROUND CORD

TEST IMPEDANCE OF AC CIRCUITS PER ANSI/ESD S6�1
PERFECT GROUNDING KIT
• Designed for 120 Volts AC Hot Neutral and Ground • Includes the Triple Socket Grounding Cube
• Measures Ground Impedance per ANSI/ESD S6.1 • Includes a 15 foot long Ground Cord
• Neutral & Ground Wires Verification per ANSI/ESD S6.1 • Includes the Sperry GFI6302 GFCI Outlet Tester
• Verifies that Hot & Neutral are not reversed • Recommended for use on tested electrical outlets
• Verifies that Hot & Equipment Ground are not reversed • Replaces expensive grounding blocks and circuit indicators GOUNDING PRODUCTS
• Line Voltage • Convenient connection for ESD grounding
• True RMS • The Sperry GFI6302 has a GFCI Test Button
• Peak Voltage • Convenient connection for ESD grounding
• Ground to neutral voltage • In accordance with IEC 61340-5-1
• Frequency • In accordance with ANSI/ESD S20.20
• Hot and neutral conductor impedances • In accordance with ANSI/ESD S6.1
• Identifies false (bootleg) grounds
• Tests GFCIs and EPDs for proper operation
• Identifies proper wiring in 3-wire receptacles

Q007-T COMMON POINT GROUND CONNECTOR ESG-030Q WIRE SHELVING GROUNDING KIT

TRIPLE RECEPTACLE GROUNDING CUBE PROVIDES AN ESD GROUND PATH The ESD Check ESG-030Q Wire Shelving Grounding Kit is an easy way to ground your
TO A PREVIOUSLY TESTED ELECTRICAL OUTLET FOR UP TO THREE already assembled wire shelving units and comply with ESD requirements� The clip
DIFFERENT ESD GROUND CIRCUITS snap onto the shelf collar to provide a current path� You then attach the alligator clip
on the ESD Clip, and use the green cord to ground your unit to the Prostat Qube�
• Recommended for use on tested electrical outlets
• Replaces expensive grounding blocks and circuit indicators • 4 each ESC-025 ESD Clips
• Convenient connection for ESD grounding • 1 each Prostat Grounding Qube
• Comes in several grounding configurations • 1 each 36" Green Ground Lead
• Use with an ESD wrist strap and ground cord for work surface grounding • 1 each Metal Alligator Clip
• Provides ESD grounding anywhere
• Made from Non-flammable materials
• Three ESD ground connection jacks on each Cube

PGC-015Q GREEN GROUND CORD & QUBE EGP-020 ESD Ground Point

GROUND CORD & QUBE ESD GROND POINT FOR EQUAL-POTENTIAL BONDING

• Includes the Triple Socket Grounding Connector
• Includes a 15 foot long Ground Cord • 4 mm Mechanical Socket
• Recommended for use on tested electrical outlets • Not insulated
• Replaces expensive grounding blocks and circuit indicators • Can be mounted on to any equipment frame
• Convenient connection for ESD grounding • Used for equal-potential bonding to the equipment
• In accordance with IEC 61340-5-1 • Includes hex nut and conical washer
• In accordance with ANSI/ESD S20.20 • Includes label identofying ESD ground point
• In accordance with ANSI/ESD S6.1

36 37
