Page 22 - Prostat catalogue
P. 22
OTHER RESISTANCE PRODUCTS ESD PACKAGING TEST KITS
PCF-825B GLOVE CAFE FIXTURE PRF-911PT ESD PACKAGING TEST KIT
TEST RESISTANCE OF GLOVES AND FINGER COTS ACCORDING TO ANSI/ESD SP15�1 TEST PACKAGING IN ACCORDANCE WITH ANSI/ESD STM11�11 AND STM11�12
• Constant Area and Force Electrode (CAFE) • Surface resistance measurements per ANSI/ESD STM11.11 ESD TEST KITS
• In-Use Resistance Testing of Gloves and Finger Cots • Volume resistance measurements per ANSI/ESD STM11.12
• Measures the Intrinsic Electrical Resistance • Meets the requirements of IEC 61340-2-3
• In Accordance with ANSI/ESD SP15.1 • Approximates surface and volume resistivity measurements per ASTM D-257
• Includes Test Leads and Wrist Strap with Ground Cord Containing an Integral 1 Megohm • Resistance measurements of ESD packaging
Resistor • Ideal for measuring static shielding and antistatic bags
• Designed to work with any Prostat Resistance Meters • Will also measure the resistance of moisture barrier bags
• Includes the PRS-801B Wide Range Resistance System
• Also includes a 5lbs weight
• Packaged in a hard shell carrying case
• Certificate of Calibration Traceable to NIST included
PGC-821 GARMENT CLIP-1 PAIR
PET-160 PACKAGING ENGINEERS TEST KIT
MEASURE RESISTANCE OF STATIC CONTROL GARMENTS
IN ACCORDANCE WITH ANSI/ESD STM2�1 PERFECT FOR DEVELOPING NEW MATERIALS OR VERIFYING EXISTING PRODUCTS
• Measure resistance of ESD garments and smocks • Measures surface resistance per ANSI/ESD STM11.11
• Meets the requirements of ANSI/ESD STM2.1 • Measures volume resistance per ANSI/ESD STM11.12
• Uses a nickel plated conductive banana jack for test lead connection • Meets the requirements of IEC 61340-2-3
• The clamp insulation is a rubber grommet measuring >1.0x10 Ohms • Measure point-to-point resistance per ANSI/ESD STM11.13
12
• Designed to work with the PRS-801B, PRS-812B or PAS-853B • Approximates surface & volume resistivity per ASTM D-257
• Includes 2 clips • Includes a concentric ring and an insulated and metal dual test bed
• Include a miniature 2-point probe
• Certificate of calibration traceable to NIST included
PRF-930 POWDER FIXTURE SET
PBT-531 SHIELDED BAG TEST KIT
FOR MEASUREMENT OF POWDERS AND GRANULATED MATERIALS�
TEST SHIELDED BAGS PER ANSI/ESD STM11�31 AND IEC 61340-4-8
• Measure the resistance of powders and granulated materials
• Meets the requirements of NIOSH-TR-No. 42 • Test shielded bag per ANSI/ESD STM11.31
• Includes caliper, spoon and brush • Also meets requirements of IEC 61340-4-8
• Grounding accessories included • Test in accordance with MIL-PRF-81705E
• Ideal for chemical, pharmaceutical, food and beverage industries • Evaluate the performance of electrostatic discharge shielded bags
• Certificate of calibration traceable to NIST included • Works with moisture barrier bags and corrugated products
• Includes portable USB PicoScope® and software
• Includes verification setup file and bag test file
• Battery operated makes it fully portable
• Computer, Laptop or Tablet not included
22 23
