FEATURED PRODUCTS

PRS-801W 5LB CONDUCTIVE RUBBER ELECTRODE
PRF-922A-B TWO-POINT PROBE ADAPTER

PROBE TO TEST RESISTANCE OF FLOORS, WORK SURFACES,
CONVERTS THE PRF-912B TO A PRECISION TWO-POINT PROBE FLOOR MATS, OR OTHER FLAT OBJECTS

• Adapter Easily Attaches to the PRF-912B • Used for point-to-point and point-to-ground resistance testing
• Measures Point-to-Point Surface Resistance of Small Areas up to 1.0x10 Ω • Provides repeatable measurements in accordance with ESD
12
• Small Enough to Measure Areas of 0.32 inches (8.13mm) Association standards
• Gold Plated Spring Loaded Contact Pins • Weighs 5lbs. (2.27kg) each ± 2 oz RESISTANCE PROBES
• Includes Rubber Covers for Measuring in Accordance with ANSI/ESD STM11.13 • Durometer hardness of 50-70
• Certificate of Calibration Traceable to NIST included • Resistance of less than 1000 ohms between two electrodes
placed on a metal test plate at 10V
• Meets the requirements of ANSI/ESD S4.1 amd ANSI/ESD S7.1

PRV-913B DUAL VERIFICATION FIXTURE PRS-801-WV PREMIUM CONDUCTIVE RUBBER ELECTRODE

VERIFY THE FUNCTIONALITY OF THE PRF-912B AND PRF-922B PROBES PREMIUM 5LBS ELECTRODES THAT MEETS ANSI/ESD S4�1

• Dual side fixture for the PRF-912B and PRF-922B AND ANSI/ESD S7�1 REQUIREMENTS
• Ensures spring loaded measurement pins compress and move freely • Ideal when qualifying or certifying material & installation
• Verifies that measurement pins are properly connected to the probe circuitry • Each electrode has a resistance of less than 10 ohms
• Provides a concentric ring reference measurement of 1.0x10 ohms • Flatness is measured and delivered within Prostat's specs
6
• Provides a 1-megohm reference measurement for two-point probes • Capped to protect the pad against deformation
• Certificate of Calibration Traceable to NIST included • In accordance with ANSI/ESD S4.1 amd ANSI/ESD S7.1
• NIST traceable certificate provided for each premium electrode

PRF-MR55 ADAPTER RINGS-SET OF 5 RINGS AND 5 BOOTS PRV-813 CONDUCTIVE RUBBER ELECTRODE VERIFIER

ADAPTERS REDUCE CONTACT RESISTANCE BETWEEN METAL ELECTRODES MEASURE FLATNESS AND RESISTANCE OF SURFACE RESISTANCE PROBES
AND SPECIALTY MATERIALS UNDER TEST
• Dual Sided Fixture for Measuring 5lbs Electrodes
• 5 Rings and 5 Boots • Contact Pad Side Measures Flatness of Rubber Pads
• Designed to minimize contact resistance and irregularities • Metal Side Measures Resistance of Electrodes
• To be used with PRS-912B, PRF-922B and PRF-922A-B • Designed to fit most Probes in the Industry
• They are installed over the contact surfaces of the miniature concentric ring electrodes • Certificate of Calibration Traceable to NIST include

PRF-MR10 RUBBER BOOTS-SET OF 10 BOOTS PRV-815 PREMIUM ELECTRODE QUALIFICATION KIT

ADAPTERS REDUCE CONTACT RESISTANCE BETWEEN METAL ELECTRODES IDEAL FOR QUALIFYING OR CERTIFYING MATERIALS
AND SPECIALTY MATERIALS UNDER TEST
• Use to Qualifying or Certifying Material & Installation
• 10 Boots • Verification fixture to measure resistance and flatness of pads included
• Designed to minimize contact resistance and irregularities • Each electrode has a resistance of less than 10 ohms
• To be used with PRS-912B, PRF-922B and PRF-922A-B • Flatness is measured and within Prostat’s Specs
• They are installed over the contact surfaces of the miniature probes • Premium Electrodes Capped to protect the pad against deformation
• Light Dressing Pad is included to clean and dress the electrode pad if needed
• Certificate of Calibration Traceable to NIST provided
