OTHER RESISTANCE PRODUCTS

ESI-870 RESISTANCE/RESISTIVITY INDICATOR

PFP-861 FOOTPLATE WITH SNAP ADAPTER
SIMPLE, REPEATABLE RESISTIVITY AND RESISTANCE MEASUREMENTS

• LED measurement indicator MEASURE THE RESISTANCE OF FOOTWEAR
• Indicates resistance in ohms per ANSI/ESD STM11.11
• Indicates resistivity in ohms/square per ASTM D-257 • Single Segment
• Resolution of one (1) order of magnitude • Stainless Steel
• Includes two (2) each machined brass, one (1) square resistivity configuration • Insulated Back Plate
• One (1) PUSH to TEST button • Snap Adapter - Banana Receptacle RESISTANCE PRODUCTS
• Battery operated • Note: Test Lead not included

PAR-809C VARIABLE RESISTANCE REFERENCE

SAVE CALIBRATION COSTS WITH IN-HOUSE PERIODIC TESTING
OF WRIST STRAP AND FOOTWEAR CHECKERS PFA-860 FOOTWEAR AUDITOR

• Perform Functional Testing of resistance equipment
• Eliminates the need for multiple units used to replace units sent for 3rd party Service MEASURE RESISTANCE OF FOOTWEAR IN COMBINATION WITH A PERSON
• Reduces Labor, freight, number of purchase orders and downtime • Designed for resistance measurements of footwear while being worn by personnel
• Uses 1% tolerance reference resistors to test PASS/FAIL settings • Measures individual body resistance through the body to the test plate
• Test resistance meters, wrist strap and, or footwear checkers
• Measures resistance through the body and shoes (one or both shoes) to the test plate
• Use to measure resistance of chairs, carts, and other mobile equipment

PWA-805 WRIST STRAP AUDITOR

TEST ESD WRIST STRAP CORDS AND CUFFS
• Measure the Interior of the Wrist Strap Cuff�
• Measure the Exterior of the Wrist Strap Cuff. PFA-861H HAND-HELD ELECTRODE
• Measure the Resistance of the Ground Cord Alone�
• Measure the Resistance of the Whole Wrist Strap Assembly�
• Measure the Resistance of Dual Wire Wrist Strap Band� HANDLE FOR MEASURING RESISTANCE THROUGH THE BODY

• Aluminum Tube
• Nickel Plated
• 4mm Banana Receptacle for Lead Connection
PMT-872A ESD WRIST STRAP/FOOTWEAR CHECKER • Meets resistance measurement requirements of TR53, ANSI/ESD STM97.1, ANSI/ESD
STM97.2 and IEC 61340-4-5
• Compatible with the PRS-801B, PRS-812B, PAS-853B and PGA-710B Walking Test System
EVALUATE THE RESISTANCE OF BOTH WRIST STRAPS AND FOOTWEAR

• Battery operated multi-function PASS/FAIL performance verifier.
• Confirms the operational resistance range of wrist straps, heel straps
and ESD controlled footwear.
• Features a large test button, audible PASS BEEP with Green PASS light,
Red LOW and HIGH Fail lights, and yellow battery low indicator.
• Additional connections are provided for an optional AC-DC Power adapter
and for testing dual conductor wrist straps.
