¼" hexagon drive, suitable for F 6.3 bit holders (series 4)

¼"

868/4 IMP DC Impaktor square-plus bits 868/4 Square-Plus bits

Application: Square socket head screws
Drive: 1 / " hexagon, suitable for DIN 3126-F 6.3, ISO 1173 bit holders
4
Application: Square socket head screws Design: Tough-absorbing, ideal for diffi cult screwdriving jobs e.g. in
Drive: 1 / " hexagon, suitable for DIN 3126-F 6.3, ISO 1173 bit holders sheet steel or metal
4
Design: The Impaktor technology ensures an above-average service
life even under extreme conditions thanks to a best-possible
utilisation of the material properties and optimally designed
geometry, particularly suitable for use with conventional impact Code mm mm
drivers, the rough diamond coating reduces the danger of any 05060150001 # 00 50 2" 3,5 10
slipping out of the screw head due to the enhanced frictional 05060155001 # 0 50 2" 3,5 10
resistance 05060160001 # 1 50 2" 4,5 10
3
05060180001 # 1 70 2 / " 4,5 10
4
1
05134800001 # 1 89 3 / " 4,5 10
2
Code mm 05134805001 # 1 152 6" 4,5 10
05057671001 # 2 50 2" 5 05060165001 # 2 50 2" 6,0 10
05057672001 # 3 50 2" 5 05060182001 # 2 70 2 / " 6,0 10
3
4
05134801001 # 2 89 3 / " 6,0 10
1
2
868/4 BTZ Square-Plus bits 05134806001 # 2 152 6" 6,0 10
05060170001 # 3 50 2" 6,0 10
05060184001 # 3 70 2 / " 6,0 10
3
4
05134802001 # 3 89 3 / " 6,0 10
1
2
05134807001 # 3 152 6" 6,0 10
Bits
05060175001 # 4 50 2" 8,0 10

Application: Square socket head screws
Drive: 1 / " hexagon, suitable for DIN 3126-F 6.3, ISO 1173 bit holders
4
Design: BiTorsion for long service life, tough-absorbing, ideal for diffi cult
screwdriving jobs e.g. in sheet steel or metal Wera ABC
Code mm mm Z Bits
05060147001 #1 50 2" 4,2 10 Tough-absorbing bits for hard
05060148001 #2 50 2" 4,2 10 materials e.g. sheet steel or metal.
05060149001 #3 50 2" 5,5 10 In this case the screw initially turns
smoothly inside the defi ned thread.
As soon as the head of the screw
touches the material surface, high
torque peaks are generated that have an aff ect on the screw
and tool. This can mean that the bit breaks if it is too hard.
Tough-absorbing Wera bits prevent any premature breakage of the
drive tip. Recognisable in the catalogue through the article letter Z.

269
