Bits for Square Socket Screws

¼" hexagon drive, suitable for D 6.3 bit holders (series 1)

¼"

868/1 IMP DC Impaktor square-plus bits

Impaktor bits and holder
For an above-average service life

Application: Square socket head screws Maximum utilisation of the material properties, a very special
geometry – designed particularly to meet the extreme demands
Drive: 1 / " hexagon, suitable for DIN 3126-D 6.3, ISO 1173 bit holders – as well a specifi c manufacturing process mean that
4
Design: The Impaktor technology ensures an above-average service Wera Impaktor tools have an above-average service life.
life even under extreme conditions thanks to a best-possible
utilisation of the material properties and optimally designed
geometry, particularly suitable for use with conventional impact Another product advantage is the coating of the Impaktor bits
drivers, the rough diamond coating reduces the danger of any with minute diamond particles. These diamond particles reduce
slipping out of the screw head due to the enhanced frictional the cam-out eff ects – particularly high in power tool applications
resistance
– which can lead to a slipping out of the screw head. The diamond
particles literally bite themselves into the screw recess.
This means that less contact pressure is required, something that
Code mm greatly delays fatigue setting-in in power tool screwdriving jobs.
05057631001 # 2 25 1" 10
05057632001 # 3 25 1" 10

868/1 BTZ Square-Plus bits

Application: Square socket head screws
Drive: 1 / " hexagon, suitable for DIN 3126-D 6.3, ISO 1173 bit holders
4
Design: BiTorsion for long service life, tough-absorbing, ideal for diffi cult
screwdriving jobs e.g. in sheet steel or metal

868/1 Z Square-Plus bits

Code mm mm
05066445001 # 1 25 1" 4,2 10
05066446001 # 2 25 1" 4,2 10
05066447001 # 3 25 1" 5,5 10
Application: Square socket head screws

Drive: 1 / " hexagon, suitable for DIN 3126-D 6.3, ISO 1173 bit holders
4
Design: Tough-absorbing, ideal for diffi cult screwdriving jobs e.g. in
sheet steel or metal

Code mm mm
05066395001 # 00 25 1" 3,5 10
05066400001 # 0 25 1" 3,5 10
05066405001 # 1 25 1" 4,5 10
05066410001 # 2 25 1" 6,0 10
05066415001 # 3 25 1" 6,0 10
05066420001 # 4 25 1" 8,0 10

268
