851/4 BTZ bits 851/4 ADC bits

Application: Phillips screws Application: Phillips screws
Drive: 1 / " hexagon, suitable for DIN 3126-F 6.3, ISO 1173 bit holders Drive: 1 / " hexagon, suitable for DIN 3126-F 6,3, ISO 1173 bit holders
4
4
Design: BiTorsion for long service life, tough-absorbing, ideal for diffi cult Design: Extra-hard, ideal for less demanding screwdriving jobs e.g. in
screwdriving jobs e.g. in sheet steel or metal wood, diamond-coated for secure screw fi t, profi led version

Code mm
Code mm mm
05059550001 PH 1 50 2" 10 05134950001 PH 1 50 2" 4,5 10
05059552001 PH 2 50 2" 10
05134951001 PH 2 50 2" 6 10
05059554001 PH 3 50 2" 10
05134952001 PH 3 50 2" - 10

851/4 A bits 851/4 J bits

Application: Phillips screws Application: Phillips screws, optimised for Asian PH screws
Drive: 1 / " hexagon, suitable for DIN 3126-F 6.3, ISO 1173 bit holders Drive: 1 / " hexagon, suitable for DIN 3126-F 6.3, ISO 1173 bit holders
4
4
Design: Extra-hard, ideal for less demanding screwdriving jobs e.g. in Design: Tough-absorbing, ideal for diffi cult screwdriving jobs e.g. in Bits
wood, profi led version sheet steel or metal

Code mm mm
Code mm mm
05134929001 PH 0 50 2" 3 10
05135530001 PH 00 50 2" 2,0 10
3
05134906001 PH 0 70 2 / " 3 10
4 05380200001 PH 00 89 3 / " 2,0 10
1
1
05134907001 PH 0 89 3 / " 3 10 2
2 05135531001 PH 0 50 2" 2,5 10
05134908001 PH 0 152 6" 3 10
05380201001 PH 0 89 3 / " 2,5 10
1
2
05134930001 PH 1 50 2" 4,5 10
05135532001 PH 1 50 2" 4,5 10
3
05134370001 PH 1 70 2 / " 4,5 10
1
4 05380202001 PH 1 89 3 / " 4,5 10
05134372001 PH 1 89 3 / " 4,5 10 2
1
2
05134909001 PH 1 152 6" 4,5 10
05134931001 PH 2 50 2" 6 10
05134371001 PH 2 70 2 / " 6 10
3
4
05134373001 PH 2 89 3 / " 6 10
1
2
05134910001 1) PH 2 152 6" 6 10 JCIS profi le
05134911001 2) PH 2 152 6" 6 10
05134932001 PH 3 50 2" - 10
05134912001 PH 3 50 2" 8 10
05134913001 PH 3 70 2 / " 8 10 Bits with the ending J are especially designed for small drive
3
4
05134914001 PH 3 89 3 / " 8 10 applications in accordance with the Japanese Camera Standard.
1
2
05134915001 PH 3 152 6" 8 10 They permit a better fi t in the screw as per this standard. However,
these screws are not only to be found in cameras, but are also
05160983001 PH 4 50 2" 10 10
used in many electrical appliances.
1) Length of drive 100 mm
2) Length of drive 20 mm
