851/4 Z bits 853/4 ACR bits

Application: Phillips screws Application: Phillips screws
Drive: 1 / " hexagon, suitable for DIN 3126-F 6.3, ISO 1173 bit holders Drive: 1 / " hexagon, suitable for DIN 3126-F 6.3, ISO 1173 bit holders
4
4
Design: Tough-absorbing, ideal for diffi cult screwdriving jobs e.g. in Design: Tough-absorbing, ideal for diffi cult screwdriving jobs e.g. in
sheet steel or metal sheet steel or metal, ACR (Anti Cam-Out Ribs) prevents bit from
slipping out of screw head

Code mm mm
05059755001 PH 1 70 2 / " 4,5 10 Code mm mm
3
4
05059760001 PH 1 89 3 / " 4,5 10 05346285001 PH 1 50 2" 3,5 10
1
2
05059765001 PH 1 127 5" 4,5 10 05346286001 PH 2 50 2" 5,2 10
05059766001 PH 1 152 6" 4,5 10 05346287001 PH 3 50 2" 5,8 10
3
05059770001 PH 2 70 2 / " 6,0 10
4
1
05059775001 PH 2 89 3 / " 6,0 10 853/4 Harpoon ACR bits
2
05059780001 PH 2 110 4 / " 6,0 10
3
8
05059785001 PH 2 127 5" 6,0 10
05059786001 PH 2 152 6" 6,0 10
3
05059790001 PH 3 70 2 / " - 10
4
05059795001 PH 3 89 3 / " - 10 Application: Phillips screws
1
2
05059800001 PH 3 110 4 / " - 10 Drive: 1 / " hexagon, suitable for DIN 3126-F 6.3, ISO 1173 bit holders
3
8
05059802001 PH 3 152 6" - 10 4
Design: Reduced shaft diameter, tough-absorbing, ideal for diffi cult
screwdriving jobs e.g. in sheet steel or metal, ACR (Anti
Cam-Out Ribs) prevents bit from slipping out of screw head Bits
Wera ABC Code mm mm
05160901001 PH 2 50 2" 3,3 10
05160895001 PH 2 70 2 / " 3,3 10
3
4
05160908001 PH 2 152 6" 3,3 10
Z Bits
Tough-absorbing bits for hard
materials e.g. sheet steel or metal.
In this case the screw initially turns
smoothly inside the defi ned thread.
As soon as the head of the screw
touches the material surface, high
torque peaks are generated that have an aff ect on the screw and
tool. This can mean that the bit breaks if it is too hard.
Tough-absorbing Wera bits prevent any premature breakage of the
drive tip. Recognisable in the catalogue through the article letter Z.
