DISMANTLING TOOLS

Universal Dismantling Tools 16
8

> for dismantling and stripping all common round and
damp proof installation cables between 8 13 mm dia
(e g 3 x 1 5 mm² up to 5 x 2 5 mm²)
> also for use in conduit and distribution boxes
> double shell, folding back stripping tool
> with opening spring and locking device
> practical clip for easy transport
16 80 125 SB
> body: plastic, fibreglass reinforced

16 85 125 SB
with additional blade for longitudinal cuts; telescopic blade inside;
stripping device for cross sections 0 2 / 0 3 / 0 8 / 1 5 / 2 5 / mm²;
with integrated cable guide for longitudinal cut This enables rigid
insulation (e g halogen free) to be stripped more easily

16 85 125 SB

EAN Stripping capacities
Article No 003773 mm Ø mm mm 2 Types of cables g
16 80 125 SB 0 0828 125 8 0 13 0 round cable, e g : 3 x 1 5 mm² up to 5 x 2 5 mm² 71
16 85 125 SB 060 125 8 0 13 0 0 2 0 round cable, e g : 3 x 1 5 mm² up to 5 x 2 5 mm² 67

Universal Dismantling Tool 16 > for dismantling and stripping all common round and
for building and industrial cables 90 damp proof installation cables between 8 0 13 0 mm dia
(e g 3 x 1 5 mm² up to 5 x 2 5 mm²)
> specially suitable for larger cross sections and for difficult
insulating materials
> no adjustment of blades to cutting depth required
> with opening spring and locking device
> stripping device for conductors and strands 1 5 mm² and 2 5 mm²
> two way length stop (ideal for right and left handers)
> fastening device on the end of the handle (fall protection)
> for use in confined and difficult to access work areas
> also for use in conduit and distribution boxes
> body: plastic, fibreglass reinforced

16 90 130 SB

EAN Stripping capacities
Article No 003773 mm Ø mm mm 2 Types of cables g
16 90 130 SB 0769 0 130 8 0 13 0 1 5 2 5 round cable, e g 3 x 1 5 mm² up to 5 x 2 5 mm² 7
