INSULATED TOOLS

Reversible Ratchet
YKVJ FTKXKPI USWCTG 98
ISO 3315 IEC 60900 DIN EN 60900 4

> reversible for clockwise and anti clockwise directions
> very reliable retention of the actuating tools ensured by
mechanically locked retaining system
> Chrome Vanadium steel
98 42

EAN Square drive
Article No 003773 mm Inch g
98 42 026525 265 1/2 599

Torque Wrenches
YKVJ FTKXKPI USWCTG TGXGTUKDNG
IEC 60900 DIN EN 60900 DIN EN ISO 6789 98

> reversible for tightening of lefthanded threads
> lockable torque adjustment
> very reliable retention of the actuating tools ensured by 98 43 50
mechanically locked retaining system
> transparent insulated scale range
> calibration certificate included
> Chrome Vanadium steel

Transparent insulated scale range

EAN Square drive
Article No 003773 mm Range of Application Inch g
98 33 25 072676 290 5 25 Nm 3/8 1230

98 33 50 071761 385 5 50 Nm 3/8 1230
98 43 50 071778 385 5 50 Nm 1/2 1230

Cable Knives 98
IEC 60900 DIN EN 60900 5

> ergonomically improved handle shape with comfortable slip guard
> particularly confident grip thanks to slip proof soft components
> thumb recess and “finger hook” at the end of the handle ensure 98 52
a good transmission of force when the blade is pulled
> solid, fixed straight blade
> transparent protective cap
> blade: special tool steel, oil hardened

98 54
back of the blade plastic coated to avoid short circuits
98 54

EAN $lade length
Article No 003773 mm Handle mm g
98 52 035565 185 insulating multi component handle, VDE tested 50 77
98 54 026563 180 insulating multi component handle, VDE tested 50 77
222
