INSULATED TOOLS

Wire Rope and ACSR-Cable Cutter 95 > for wire ropes and steel rods, copper and aluminium cables
IEC 60900 DIN EN 60900 7 > suitable for cutting overhead line cables with strain relief wire
(ACSR cables)
> angular cutting blades allow cutting of single rope wire
> optimum transmission ratio for high cutting performance
> bolted cutter head, replaceable low weight
> cutter head: high grade special tool steel, multi stage oil hardened
> handles: aluminium, highstrength

95 77 600

Cutting capacities
EAN
Article No 003773 mm Head Handles mm² Ø mm Ø mm AWG g
95 77 600 025313 600 polished with dipped insulation 150 1 0 9 0 5/0 2359
95 79 600 025337 Spare cutter head for 95 71 600 / 95 77 600

Crimping Pliers for end sleeves
(ferrules) 97
IEC 60900 DIN EN 60900 68

> for crimping end sleeves (ferrules) according to DIN 6228 parts 1
in the range from 0 25 up to 2 5 mm²
> crimping in marked trapezoidal dies for reliable connections between
the sleeve and the conductor 97 68 145 A
> Vanadium electric steel; forged, oil hardened

EAN Capacity Number of crimping
Article No 003773 mm Head Handles mm² AWG positions g
insulated with multi component
97 68 145 A 07175 1 5 polished 0 25 2 5 23 13 175
grips, VDE tested

Crimping Pliers for end sleeves > for crimping end sleeves (ferrules) according to DIN 6228
(ferrules) parts 1 from 0 25 to 16 mm²
IEC 60900 DIN EN 60900 97 > easy crimping due to optimised transmission ratio
> light and slim design
> crimping in marked half round dies for reliable connections
between the sleeve and the conductor
> 9 particularly deep dies with conical side faces
> Special tool steel, forged, oil hardened

97 78 180

EAN Capacity Number of
Article No 003773 mm Head Handles mm² AWG crimping positions g
insulated with multi component grips,
97 78 180 072003 180 polished 0 25 16 23 5 9 25
VDE tested
