CRIMPING PLIERS

Crimping Pliers 97
also for two-hand operation 52

> for solder free electrical connections
> the ingenious lever transmission reduces the handforce up to 30 %
compared with regular crimping pliers
> repetitive, high crimping quality due to precision dies and integral lock 97 52 04
(self releasing mechanism)
> crimping pressure has been set precisely (calibrated) in the factory,
re adjustable
> two hand operation for easy crimping of large conductor diameters
> easy handling as a result of well balanced centre of gravity,
angled head and ergnomically shaped handles
Product video
> Chrome vanadium electric steel in special quality, oil hardened

97 52 06

97 52 10
First step: move the handle with two fingers Second step: now use the whole hand for Third step: when greater hand force is
only until both jaws touch the connector to further crimping procedure required, such as e g when crimping insulated
be crimped connectors 6 mm², two hand operation is
possible by the longer handles

EAN Capacity
Article No 003773 mm Applications mm² AWG g
2 8 mm: 0 1 0 25
non insulated open plug type connectors 2 8 mm: 0 5 1
97 52 04 025 50 250 (plug width 2 8 8 mm) 8 mm: 0 5 1 27 13 562
8 mm: 1 5 2 5
0 5 1
non insulated open plug type connectors
97 52 05 025 67 250 1 5 2 5 20 10 572
(plug width 2 8 8 mm)
6
0 5 1
97 52 06 025 7 250 insulated terminals, plug connectors and butt connectors 1 5 2 5 20 10 565
6
0 25 0 75
1 1 5
97 52 08 025 81 250 insulated and non insulated end sleeves (ferrules) 2 5 23 10 565

6

97 52 09 025 98 250 insulated and non insulated end sleeves (ferrules) 10 / 16 / 25 7/ 5/ 3 571

97 52 10 023678 250 Coax , $NC and TNC connectors 577
non insulated crimp terminals, tube and compression cable lugs 0 5 1
in accordance with DIN 623 and DIN 6235 and non insulated 1 5 2 5
97 52 13 0 808 250 crimp, butt and press connectors in accordance with DIN 63 1 and 6 20 7 558
DIN 6267 10

97 52 19 0521 2 250 insulated and non insulated end sleeves (ferrules) 35 / 50 2 / 0 567

97 52 23 052159 250 non insulated terminals cable connectors 16 / 25 5 / 3 565

97 49 94 030997 Locator for 97 9 0 / 97 52 0 / 97 52 3
97 49 95 031000 Locator for 97 9 05 / 97 52 05 / 97 52 35
