CIRCLIP PLIERS

Precision Circlip Pliers
to assemble internal circlips into bores
DIN 5256 48

With inserted tips for reliable work
*GCX[ FWV[ KP EQPVKPWQWU QRGTCVKQP WR VQ VKOGU
NQPIGT UGTXKEG NKHG EQORCTGF VQ VWTPGF VKRU
> bolted joint: precise, zero backlash operation of pliers 48 11 J2
> non slip plastic coating on the handles
> pliers body: chrome vanadium electric steel, forged, oil hardened
> inserted tips: spring steel wire, drawn

Style 1
DIN 5256 C; straight tips
Style 2
DIN 5256 D; 90° angled tips
48 21 J21
90°

High precision quality

Easy and reliable assembly: form-fitting inserted and pressed-in tips
OCFG QH JKIJ FGPUKV[ URTKPI UVGGN QHHGT C JKIJ NGXGN QH RTQVGEVKQP
CICKPUV GZEGUUKXG UVTGUU CPF UVTCKP G I YJGP TGOQXKPI UVWEM TKPIU
The large supporting surfaces and the position of the tips make it
more difficult for the rings to bounce off.

Precision and durability
High density spring steel with a score free surface is used for the tips
This increases the tips‘ resistance to dynamic and static strain The tips
are 30 % more stable than conventional pliers when subjected to one off
overloading while still allowing good accessibility during assembly
Subjected to dynamic strain, the tips‘ resistance capacity is up to 10 times
greater The tips on the precision circlip pliers are non detachable

Sturdy, inserted tips: Tight fit through compression
made from high density spring steel

EAN Size of bore Tips
Article No 003773 mm Style Pliers Handles Ø mm Ø mm g
48 11 J0 0 8510 1 0 8 13 0 9 105
48 11 J1 0 8527 1 0 12 25 1 3 105
48 11 J2 0 853 180 1 grey atramentized with non slip plastic coating 19 60 1 8 175
48 11 J3 0 85 1 225 0 100 2 3 266
48 11 J4 0 8558 320 85 1 0 3 2 580
48 21 J01 0 8619 130 8 13 0 9 105
48 21 J11 0 8633 130 12 25 1 3 105
48 21 J21 0 86 0 165 90° 2 grey atramentized with non slip plastic coating 19 60 1 8 175
48 21 J31 0 8657 210 0 100 2 3 265
48 21 J41 0 866 305 85 1 0 3 2 576
