SMT Rework

Convective systems use hot air to reflow solder joints and are often thought of as a “safer” method for
removing and installing components from PCBs because of the non-contact process.
ST925

SMT Rework Station

PN: 8007-0576 (120 V), 8007-0577 (230 V)
The ST925 combines three popular PACE products together into one
convenient, low-cost SMT Rework System. The system is comprised of
the ST325 Programmable Convective/Hot Air Rework Station, the PH100
Low Profile Infrared Preheater and ST500A Z-Axis Platform. Together, the
system provides a 575 Watt convective top-side heater plus a 1600 Watt IR
bottom-side preheater which allows operators to safely rework PCBs.

ST325 Hot Air Rework Station PH100 Preheater
PN: 8007-0429 (120 V), 8007-0432 (230 V) PN: 8007-0572 (120 V), 8007-0573 (230 V)
The ST325 is a digital, self-contained
system that is fully programmable and The PACE PH 100 is a high powered
can be used to remove or install surface (1600W), non-contact infrared
mount components. A vacuum pick for (IR) underheating system with an
holding/lifting components is a standard ergonomic, low-profile design which
feature. Handpiece includes spring permits operators to safely pre-heat
loaded vacuum pick with 3 sizes of PCB’s for fast, efficient soldering, rework
vacuum cups. or repair, even on the highest mass,
thermally challenging, lead-free PCB’s.

PACE’s family of hot air rework systems are ideal for all SMT applications. A wide range of product features are available to meet your specific needs.
They can be easily upgraded by adding one of our powerful pre-heaters and/or PCB holders.

ST400 IR Preheater IR1000 IR Rework System
PN: 8007-0435 (120 V), 8007-0436 (230 V) PN: 8007-0536 (120 V), 8007-0537 (230 V)
The ST400 is an analog (dial), The IR1000 is capable of installing
closed loop temperature and removing almost any SMD
controlled pre-heater with a Component. It incorporates a
400W radiant (medium/long 500W top heater and a 400 W
wave IR) heater. Temperatures pre-heater. The system features a
range 37°C - 205°C (100°F spring loaded, adjustable vacuum
- 300°F). pik, a cooling fan, and a built-in,
spring loaded, board-holder.

Modular Accessories ST525
PN: 6993-0253-P1

Product Description Part Number

ST500 Z-Axis Platform Z-Axis stand for the ST 300/325 handpiece 6993-0258-P1
ST500A Adjustable Z Z-Axis stand for the ST 300/325 handpiece/Fits PH-100 Preheater 6993-0258-P1
ST525 PCB Holder Spring loaded board holder, holds up to 12”x12” PCBs 6993-0253-P1
ST500A
ST550 PCB Holder Spring loaded board holder, holds up to 18”x18” PCBs 6993-0254-P1 PN: 6993-0258-P1
