Pliers | Stripping pliers
Stripping pliers
Side cutters and tip cutters
High precision stripping pliers
Pliers for front stripping 0.25 mm – 1.02 mm .010 Inch – .040 Inch (AWG 30 – 18)
4.724 Inch / 120 mm Robust, high-precision tools for use in
2.65 / 75 g electronics and aeronautical engineering
The required diameter is set
by means of screws
ESD-safe Pliers
Suitable for all types of insulation
and optical fibres.
Interchangeable side cutting blade.
A = jaw length
E = Width of tips
G = Total height of both tips
H = Length of cutting blade
Model A E G H Wire diameter
Inch mm Inch mm Inch mm Inch mm Inch mm Tweezers
510AE 0.83 21 0.20 5 0.16 4 0.35 9 0,010 - 0,040 0,25 - 1,02
Pliers for front stripping 0.06 mm – 0.6 mm .002 Inch – .023 Inch (AWG 42 – 24)
4.724 Inch / 120 mm Robust, high-precision tools for use in
2.82 / 80 g electronics and aeronautical engineering
The required diameter is set
by means of screws
Screwdriver and key are included
Interchangeable blades Special tools
ESD-safe
Unique precision for damage-
free stripping of fine wires.
A = Jaw length Suitable for all types of insulation,
E = Width of tips Teflon®, Tefzel and optical fibres.
F = Depth of interchangeable blade
G = Total height of both tips
H = Length of cutting blade
Model A E F G H Wire diameter
Inch mm Inch mm Inch mm Inch mm Inch mm Inch mm
552E 0.91 23 0.24 6 0.39 1 0.43 11 0.35 9 0,002 - 0,023 0,06 - 0,6
Kits
Precision Tools 345
