Pliers | Forming pliers
Forming pliers
Side cutters and tip cutters
Forming pliers for passive components
Forming pliers for component connection, U-shape.
Pliers
4.724 Inch / 120 mm
2.47 / 70 g
Safe bending, forming and preparation
of component connections A = Jaw length
Non-reflecting surface D = Height of tips
ESD-safe E = Width of tips
F = Length of forming
Model A D E F Diodes Capacitors Resistors
Inch mm Inch mm Inch mm Inch mm Inch mm Inch mm
554E 0.513 13 0.394 10 0.394 10 0.394 10 0.025 0.65 0.027 0.7 1/2 W
Tweezers
Forming pliers for component connections, U-shape, axial forming.
4.724 Inch / 120 mm
2.47 / 70 g Special tools
Suitable for component connections,
U-shape, axial forming A = Jaw length
Narrow head shape. D = Height of tips
ESD-safe E = Width of tips
F = Length of forming
Model A D E F Diodes Capacitors resistors
Inch mm Inch mm Inch mm Inch mm Inch mm Inch mm
554A 0.905 23 0.25 6.4 0.158 4 0.16 4 0.025 0.65 0.027 0.7 1/2 W
Kits
Precision Tools 347
