Shelving cabinets

Shelving cabinets are made of epoxy powder coated steel. The frames are painted with light grey RAL 7035 and doors
either with blue RAL5007 or with light grey RAL7035. The cabinet has sturdy double leaf-doors, flush fitting handle with
two keys. Shelving cabinet can be moved with fork lift. There are leveling screws under the cabinet for adjusting the cabinet
straight. The shelving cabinets are pre-assembled.

Loading capacity 150kg/shelf, 600kg/cabinet.

! Move with a pallet truck
The cabinet can be moved with a
pallet truck or a forklift when it is
empty. Cabinets are equipped with
adjustment screws.

INDUSTRIAL SHELVING AND CABINETS Heavy storage system
Name Size W x D x H mm Code blue Code grey
Shelving cabinet 100/40/200 1030 x 430 x 2010 SC10040200-07 SC10040200-49
Shelving cabinet 100/50/200 1030 x 530 x 2010 SC10050200-07 SC10050200-49
Shelving cabinet 100/60/200 1030 x 630 x 2010 SC10060200-07 SC10060200-49
Includes 4 shelves. For additional shelves and perforated panel see page 80.

! The W x D x H rule Load capacity
All our dimensions follow a WDH rule, where the first
dimension is the width (W), the middle the depth (D), and
the last the height (H).
150 kg/shelf

Combination name
600 kg/cabinet

100/40/200

Width cm Depth cm Height cm
