! How to read the codes of drawer units
• The number included in the general name of the
drawer unit refers to the base unit width in centimetres.
• The second number refers to the base unit height.
• The third number refers to the combination.

Example: Drawer unit 55/66-1
The drawer unit is 55 cm wide, 66 cm high and its
combination number is 1.

Drawer unit 45/14 and 45/26

Drawer unit 45 is attached under the workbench. It comes with fully opening
drawers.

140 mm
Drawer units 45/14 and 45/26
Model Opening Load capacity Outer dims Height (mm) Code 520 mm
kg / drawer W x D x H mm of the drawer
450 mm
45/14-1 100% 60 450 x 520 x140 1 x 100 603 49 001

45/26-1 100% 60 450 x 520 x 260 2 x 100 604 49 001
Internal drawer dimensions: 380 x 500 x 90 mm.
260 mm

Drawer interiors 520 mm 450 mm
DRAWER UNITS Drawer unit 45

Divider set 1 Divider set 2 Divider set 3 Divider set 4
Model Code Model Code Model Code Model Code
Drawer 45/100 872 991-49 Drawer 45/100 872 992-49 Drawer 45/100 872 993-49 Drawer 45/100 872 994-49
4 x horizontal dividers 375 1 x vertical divider, 8 x divider 1 x vertical divider, 4 x divider 2 x vertical divider, 12 x divider
plate 185 plate 125, 4 x divider plate 250 plate 125

Treston - Distinctive workshops 59
