conductive bins ESD

6. Stacking bins

For use on louvred panel and rail systems. Their open front design gives good access.
Corrugated base eases the picking of the smallest of items. Material: Semiconductive
polypropylene (PP). Accessories: Cross dividers are of semiconductive epoxy powder
coated steel. Label with shield, shields are not conductive.

Code Outer dims Dividers Labels
D x W x H mm (orderedseparately) (orderedseparately)

1015-4ESD 165 x 105 x 75 — E-10

1520-4ESD 192 x 149 x 105 — E-15

1525-4ESD 250 x 149 x 130 V-14 E-15

1930-4ESD 300 x 186 x 156 V-19 E-20

6 1940-4ESD 400 x 186 x 156 V-19 E-20

1950-4ESD* 510 x 186 x 182 V-195 E-20

3040-4ESD* 400 x 310 x 182 V-30 E-20

3050-4ESD* 500 x 310 x 182 V-30 E-20

7. Storage boxes

Straight sided storage boxes of 18 and 36 litre capacity are used for internal and
external transport systems. These have integral handles and stack securely together.
Material: Semiconductive polystyrene (PS).

Code Outer dims
10-18L-4ESD D x W x Hmm
535 x 323 x 150

10-36L-4ESD 508 x 323 x 280

7
*) Made only to order. Please ask for details.

stacking bin stands, trolley

Single stand BS-160LA ESD Double stand BS-160TA ESD Trolley BT-170A ESD
• as double stand
• free standing frame of semiconductive epoxy • free standing frame of semiconductive epoxy • bottom shelf of 12 mm ESD-laminate
powder coated steel in light grey RAL 7035 powder coated steel in light grey RAL 7035 • 4 castors Ø 100 mm which two are

• 8 adjustable, double sided bin rails, length • 8 adjustable bin rails, length 740 mm. conductive and two braked
740 mm • Stacking bins are ordered separately. • load capacities: trolley 150 kg
• Load capacity 240 kg • size D x W x H: 600 x 820 x 1700 mm
• stacking bins are ordered separately • size D x W x H: 600 x 820 x 1585 mm
• load capacity 120 kg One rail will hold
• size D x W x H: 420 x 820 x 1585 mm One rail will hold 14 pcs 1015-4ESD
14 pcs 1015-4ESD 10 pcs 1520-4ESD
One rail will hold either 10 pcs 1520-4ESD 10 pcs 1525-4ESD
7 pcs 1015-4ESD 10 pcs 1525-4ESD 8 pcs 1930-4ESD.
5 pcs 1520-4ESD 8 pcs 1930-4ESD.
5 pcs 1525-4ESD
4 pcs 1930-4ESD.
