Page 46 - WERA katalógus

Kraftform Plus – Series 300

The right tool for every application

? VSM
345 VSM Slotted screwdriver

Application: Slotted screws
Blade: Round, sizes 6-7 with square neck Damage to slotted screws is avoided
Design: Black Point with the plane-parallel cut of the VSM
Handle: Kraftform with non-roll feature, multi-component series. It is particularly suitable for
semi-hard screws made out of brass,
for example.
Code # mm mm mm mm
05133120001 00 0,3 2,0 60 70 2 / " 10
3
8
05133121001 0 0,4 2,5 75 70 3" 10
05133122001 1 0,5 3,5 80 81 3 / " 10
1
8
1
05133123001 2 0,6 4,0 90 98 3 / " 10
2
05133124001 3 0,8 5,5 100 98 4" 10
05133125001 4 1,0 6,5 125 105 5" 10 350 PH Screwdriver for Phillips screws
05133126001 5 1,2 8,0 150 105 6" 10
05133127001 6 1,6 10,0 175 112 7" 10
05133128001 7 2,0 13,0 200 112 8" 2

Application: Phillips screws
Blade: Round
Design: Chrome-plated, Lasertip
Handle: Kraftform with non-roll feature, multi-component

Code mm mm mm
05008705001 1) PH 0 60 81 3,0 2 / " 5
3
8
05008706001 1) PH 0 100 81 3,0 4" 5
05008710001 PH 1 80 98 4,5 3 / " 10
1
8
05008712001 PH 1 200 98 4,5 8" 2
05008715001 1) PH 1 300 98 4,5 12" 2
05008720001 PH 2 100 105 6,0 4" 10
05008723001 PH 2 150 105 6,0 6" 5
05008725001 PH 2 200 105 6,0 8" 2
05008730001 1) PH 2 300 105 6,0 12" 2
05008735001 PH 3 150 112 8,0 6" 5
05008740001 1) PH 4 200 112 10,0 8" 2
1) without Lasertip

42
